Advanced ASIC Chip Synthesis: Using Synopsys' Design Compiler and PrimeTime

by Himanshu Bhatnagar

Overview

Advanced ASIC Chip Synthesis: Using Synopsys® Design Compiler® and PrimeTime® describes the advanced concepts and techniques used for ASIC chip synthesis, formal verification and static timing analysis, using the Synopsys suite of tools. In addition, the entire ASIC design flow methodology targeted for VDSM (Very-Deep-Sub-Micron) technologies is covered in detail.
The emphasis of this book is on real-time application of Synopsys tools used to combat various problems seen at VDSM geometries. Readers will be exposed to an effective design methodology for handling complex, sub-micron ASIC designs. Significance is placed on HDL coding styles, synthesis and optimization, dynamic simulation, formal verification, DFT scan insertion, links to layout, and static timing analysis. At each step, problems related to each phase of the design flow are identified, with solutions and work-arounds described in detail. In addition, crucial issues related to layout, which includes clock tree synthesis and back-end integration (links to layout) are also discussed at length. Furthermore, the book contains in-depth discussions on the basics of Synopsys technology libraries and HDL coding styles, targeted towards optimal synthesis solutions.
Advanced ASIC Chip Synthesis: Using Synopsys® Design Compiler® and PrimeTime® is intended for anyone who is involved in the ASIC design methodology, starting from RTL synthesis to final tape-out. Target audiences for this book are practicing ASIC design engineers and graduate students undertaking advanced courses in ASIC chip design and DFT techniques.
From the Foreword:
'This book, written by Himanshu Bhatnagar, provides a comprehensive overview of the ASIC design flow targeted for VDSM technologies using the Synopsis suite of tools. It emphasizes the practical issues faced by the semiconductor design engineer in terms of synthesis and the integration of front-end and back-end tools. Traditional design methodologies are challenged and unique solutions are offered to help define the next generation of ASIC design flows. The author provides numerous practical examples derived from real-world situations that will prove valuable to practicing ASIC design engineers as well as to students of advanced VLSI courses in ASIC design'.
Dr Dwight W. Decker, Chairman and CEO, Conexant Systems, Inc., (Formerly, Rockwell Semiconductor Systems), Newport Beach, CA, USA.

Product Details

ISBN-13:	9780792385370
Publisher:	Springer-Verlag New York, LLC
Publication date:	06/28/1999
Pages:	284
Product dimensions:	6.14(w) x 9.21(h) x 0.75(d)

About the Author

Himanshu Bhatnagar is a Senior ASIC Design Engineer at Conexant Systems, Inc. based in Newport Beach, California. Conexant Systems Inc., formerly Rockwell Semiconductor Systems, is the world's largest independent company focused exclusively on providing semiconductol products for communication electronics. Himanshu has been instrumental in defining the next generation ASIC design flow methodologies using latest high performance tools from Synopsys and other EDA tool vendors.

Before Joining Conexant, Himanshu worked for SGS-Thomson Microelectronics in Singapore and the corporate headquarters based in Grenoble, France. He completed his undergraduate degree in Electronics and Computer Science from Swansea University (Wales, UK), and his masters degree in VLSI design from Clemson University, (South Carolina, USA).

Read an Excerpt

Chapter 1: ASIC Design Methodology

1.1.4 Formal Verification

The concept of formal verification is fairly new to the ASIC design community. Formal verification techniques perform validation of a design using mathematical methods without the need for technological considerations, such as timing and physical effects. They check for logical functions of a design by comparing it against the reference design.

A number of EDA tool vendors have developed the formal verification tools. However, only recently, Synopsys also introduced to the market its own formal verification tool called Formality.

The main difference between formal methods and dynamic simulation is that the former technique verifies the design by proving that the structure and functionality of two designs are logically equivalent. Dynamic simulation methods can only probe certain paths of the design that are sensitized, thus may not catch a problem present elsewhere. In addition, formal methods consume negligible amount of time as compared to dynamic simulation.

The purpose of the formal verification in the design flow is to validate the RTL against RTL, gate-level netlist against the RTL code, or the comparison between gate-level to gate-level netlists.

The RTL to RTL verification is used to validate the new RTL against the old functionally correct RTL. This is usually performed for designs that are subject to frequent changes in order to accommodate additional features. When these features are added to the source RTL, there is always a risk of breaking the old functionally correct feature. To prevent this, formal verification may be performed between the old RTL and the new RTL to check the validity of the old functionality.

The RTL to gate-level verification is used to ascertain that the logic has been synthesized accurately by DC. Since the RTL is dynamically simulated to be functionally correct, the formal verification of the design between the RTL and the scan inserted gate-level netlist assures us that the gate-level also has the same functionality. In this instance if we were to use the dynamic simulation method to verify the gate-level, it would have taken a long time (days and weeks, depending on the size of the design) to verify the design. In comparison, the formal method would take a few hours to perform a similar verification.

The last part involves verifying the gate-level netlist against the gate-level netlist. This too is a significant step for the verification process, since it is mainly used to verify - what has gone into the layout versus what has come out of the layout. What comes out of the layout is obviously the clock tree inserted netlist (flat or hierarchical). This means that the original netlist that goes into the layout tool is modified. The formal technique is used to verify the logic equivalency of the modified netlist against the original netlist.

1.1.5 Static Timing Analysis using PrimeTime

As previously mentioned, the block level static timing analysis is done using DC. Although, the chip-level static timing can be performed using the above approach, it is recommended that PrimeTime, be used instead. PrimeTime is the Synopsys stand-alone sign-off quality static timing analysis tool that is capable of performing extremely fast static timing analysis on full chip-level designs. It provides a Tcl interface that provides a powerful environment for analysis and debugging of designs.

The static timing analysis, to some extent, is the most important step in the whole ASIC design process. This analysis allows the user to exhaustively analyze all critical paths of the design and express it in an orderly report.

Furthermore, the report can also contain other debugging information like the fanout or capacitive loading of each net.

The static timing is performed both for the pre and post-layout gate-level netlist In the pre-layout mode, PrimeTime uses the wire load models specified in the library to estimate the net delays. During this, the same timing constraints that were fed to DC previously are also fed to PrimeTime, specifying the relationship between the primary I/0 signals and the clock. If the timing for all critical paths is acceptable, then a constraints file may be written out from PrimeTime or DC for the purpose of forward annotation to the layout tool. This constraint file in SDF format specifies the timing between each group of logic that the layout tool uses, in order to perform the timing driven placement of cells.

In the post-layout mode, the actual extracted delays are back annotated to PrimeTime to provide realistic delay calculation. These delays consist of the net capacitances and interconnect RC delays.

Similar to synthesis, static timing analysis is also an iterative process. It is closely linked with the placement and routing of the chip. This operation is usually performed a number of times until the timing requirements are satisfied.

1.1.6 Placement, Routing and Verification

As the name suggests, the layout tool performs the placement and routing. There are a number of methods in which this step could be performed. However, only issues related to synthesis are discussed in this section.

The quality of floorplan and placement is more critical than the actual routing. Optimal cell placement location, not only speeds up the final routing, but also produces superior results in terms of timing and reduced congestion. As explained previously, the constraint file is used to perform timing driven placement. Although this is the recommended approach, sometimes this approach leads to significant impact on the overall area. However, in general, the area is decreased due to rubber-banding effect of the timing driven placement approach. It is up to the user's discretion to.....
