Audio Wiring Guide: How to wire the most popular audio and video connectors

by John Hechtman

Overview

Whether you're a pro or an amateur, a musician or into multimedia, you can't afford to guess about audio wiring. The Audio Wiring Guide is a comprehensive, easy-to-use guide that explains exactly what you need to know. No matter the size of your wiring project or installation, this handy tool provides you with the essential information you need and the techniques to use it. Using The Audio Wiring Guide is like having an expert at your side. By following the clear, step-by-step directions, you can do professional-level work at a fraction of the cost. Every step is clearly explained and photo-illustrated. All the common audio connectors are covered as well as most special-use multimedia connectors. It is the perfect guide to keep by your side in the studio or on the road.

Product Details

ISBN-13:	9781138406612
Publisher:	Taylor & Francis
Publication date:	08/11/2017
Pages:	336
Product dimensions:	9.25(w) x 7.50(h) x (d)

About the Author

John Hechtman is a skilled recordist and technical writer, with 40 years of professional audio experience. He has built or rewired over 20 pro-level studios, along with dozens of semi-pro installations. Currently he is a freelance computer/audio consultant

Table of Contents

Basic Information; Soldering Techniques; Use of Spreadsheets; Grounding Schemes; The Connectors: Guitar plug - stereo male w/mono inserts; Guitar plug - stereo female w/mono inserts; XLR 3 pin male & female combined; RCA plug male (new style); RCA plug female (new style); TT (Bantam) plug (male); BNC video male (crimped plug - male only); F connector video (crimped plug - male only); Mini male stereo guitar plug 1/8" dia.Industry standards
