Citrix XenDesktop Implementation explores the implementation of Citrix XenDesktop, a virtual desktop infrastructure solution. After introducing the desktop virtualization, the book discusses the installation of a desktop delivery controller through advanced XenDesktop Client Settings.
This book briefly discusses the work of desktop delivery controller mechanisms


Citrix XenDesktop Implementation explores the implementation of Citrix XenDesktop, a virtual desktop infrastructure solution. After introducing the desktop virtualization, the book discusses the installation of a desktop delivery controller through advanced XenDesktop Client Settings.
This book briefly discusses the work of desktop delivery controller mechanisms followed by its installation process, integration process of XenDesktop with Microsoft Active Directory, and the configuration of the desktop delivery controller. It then examines the process of installing the virtual desktop onto the server infrastructure, and it follows the installation and integration onto Xen Server, Hyper-V, and VMware hypervisors. Furthermore, it discusses the advanced configuration settings.
The book covers the installation of the Citrix Provisioning Server and its fundamental configuration. It also explores the configuration of Citrix XenApp for Application provisioning, the integration of virtual applications, and the implementation of virtual profiles into the virtual desktop. The book concludes by explaining the advanced XenDesktop client settings on audio, video, and peripherals.

    • Ideal one-stop handbook for implementing a Citrix XenDesktop virtual desktop solution
    • Includes all technical details required for you to evaluate how Citrix XenDesktop would integrate into your existing environment
    • Covers integration with VMware ESX/vSphere, Microsoft Hyper-V including System Center Virtual Machine Manager (SCVMM) and Citrix XenServer

    Editorial Reviews

    From the Publisher
    "Gareth James does an amazing job diving deep in to what you truly need to know in order to successfully implement and deploy Citrix XenDesktop. I highly recommend this book to anyone looking into and/or deploying XenDesktop. 5 Stars!"

    - Douglas A. Brown, CEO and Founder DABCC, Inc., Microsoft MVP Windows Server, Citrix Technology Professional

    Product Details

    Elsevier Science
    Publication date:
    Sold by:
    Barnes & Noble
    NOOK Book
    Sales rank:
    File size:
    18 MB
    This product may take a few minutes to download.

    Read an Excerpt

    Citrix XenDesktop Implementation

    A Practical Guide for IT Professionals
    By Gareth R. James


    Copyright © 2010 Elsevier Inc.
    All right reserved.

    ISBN: 978-1-59749-583-7

    Chapter One



    • Desktop Virtualization

    • Components of a Citrix VDI Solution

    • The Project-Based Approach

    Desktop virtualization is a very broad topic, which can encompass various virtualization technologies. This book is aimed at specifically addressing how to implement a virtual desktop infrastructure (VDI) solution using Citrix XenDesktop.

    This book is not meant as a definitive guide to any one of the technologies discussed in this book, but sets out to tie the components together in a simple, easy-to-grasp manner. We certainly hope it enables you, the reader, to accelerate through the discovery stage, straight through to implementing your own proof of concept or pilot of the technology.


    Desktop virtualization has become a catch all phrase for various mechanisms that simplify the management of the user's desktop environment.

    VDI is a concept that has been around for some years. The basic concept is to host the desktops in the datacenter rather than on the user's desk. This concept was pioneered by Hewlett-Packard about 5 years ago. The first iteration of the idea involved taking a rack of blade computers, and installing Windows XP on each blade; users then accessed their assigned blade using a standard Microsoft RDP (Remote Desktop Protocol) client. As a concept, it worked for some high-end requirements. The advent of server virtualization into the mainstream has meant that we can now host 30+ desktops on a single server, such that this technology is now far more affordable. Figure 1.1 is a diagram of a basic VDI.

    The Client Hypervisor is another desktop virtualization technology. The Client Hypervisor entails installing a hypervisor on a laptop or PC, which is used to host one or more desktop operating systems. This technology should not be confused with "Type 2" hypervisors like virtual PC or VMware workstation that execute on top of a guest operating system. This differs from a server hypervisor insofar as it allows the guest operating system to be accessible from the device itself. This includes exposing peripherals like USB (Universal Serial Bus), LPT ports, and importantly the graphics processing unit direct to the guest operating system. The user can thus access the guest operating system (Windows 7, for example) as if it were locally installed. There are plans to dovetail this (currently beta) technology into VDI, such that you could access the same guest virtual machine (VM) using the VDI-hosted mechanism, or even "check out" the VM by dragging the whole VM virtual disk down to a laptop to make it available offline.

    Depending on your point of view (or who you work for), Microsoft Remote Desktop Services (RDS) — formerly called Terminal Services — Citrix XenApp, Presentation Server, or MetaFrame is also regarded as a form of desktop virtualization. The difference between this method and VDI is that the operating system used is shared by multiple users, and that it is implemented on a Microsoft server rather than a Microsoft desktop operating system. Additionally, because the overhead of running the operating system is shared rather than requiring an individual instance per user, one typically achieves a higher user density using RDS over VDI. Most organizations would benefit from having a blend of both technologies, with RDS catering for minimal environment, task-based users, and VDI providing a richer environment for the users with higher resource requirements. Microsoft has included RDS CAL in its premium VDI suite, such that the user can connect to a hosted desktop operating system, or a server operating system using RDS, or indeed both if required. Citrix, likewise, both as part of desktop virtualization and their new XenDesktop 4 licensing model, allows the user to use a hosted desktop operating system (XenDesktop) and also to connect to a server desktop using their XenApp product, as part of the same licensing suite. For the sake of clarity, I will refer to the Citrix VDI solution as XenDesktop, and to the RDS (Terminal Services) solution as XenApp, although both products are included in the XenDesktop 4 license suite.

    Desktop streaming is a further type of desktop virtualization. VDI and RDS are datacenter-based solutions and the Client Hypervisor is client end virtualization, desktop streaming is a combination of both. Desktop streaming involves mounting a virtual disk over the network to a physical device. The device could be a normal PC or a diskless device. Based on the MAC address of the machine, either you could choose a virtual disk to mount or the administrator could assign one to the MAC address. Citrix Provisioning Server is a mature technology that Citrix acquired when they bought Ardence back in 2006. Dell uses this technology as part of its "Flexible Computing Solution" and refers to it as on-demand desktop streaming (ODDS). This technology can be used with physical or even VMs! Citrix integrates the technology into its XenDesktop VDI solution, but it is important to note that it can be used separately and is a valid solution in its own right.

    Application virtualization is sometimes included in the definition of desktop virtualization — whether you include it in the definition or not, it should most certainly be included as part of your implementation. Application virtualization products include Citrix XenApp streaming and Microsoft App-V. Both products function in a similar way, instead of installing each application into the operating system, embedding themselves into the file system and registry, the applications are presented with a virtual file system and a virtual registry, unique to that application. Streamed applications work in an isolation environment. This means that applications don't conflict with each other, and they don't need to be installed in order to execute. Decoupling the application from the host operating system means we greatly simplify the application management on our desktop. This modular approach means that we can easily build out complex and unique guest environments from commonly used building blocks.

    Virtual Profiles is another component commonly used within the framework of desktop virtualization. Virtual Profiles fits into the category of "complementary technology." Virtual Profiles is an extension of the roaming profile concept. Roaming profiles is essentially the ability to centralize the user settings on a file share, Virtual Profiles extends this capability to include files and registry keys not traditionally included in the users settings. Virtual Profiles also includes sophisticated mechanisms for managing user settings, including the ability to merge settings from multiple user sessions, and to do intelligent conflict handling. Virtual Profiles provides a more robust solution for handling a situation where users may have multiple access mechanisms to access their working environment.


    The Citrix approach to VDI is a layered, modular approach. This approach allows you to leverage different technologies at each layer, when composing the overall solution (see Figure 1.2).

    Starting at the server hardware level, the Citrix solution is hypervisor agnostic. The hypervisor may be Citrix's XenServer, Microsoft's Hyper-V, or VMware's ESX/vSphere (see Figure 1.3).

    Next, you make use of Citrix's provisioning server to mount a virtual disk into the VM — this technology is the one most people are unfamiliar with — it allows you to use one virtual disk to boot multiple VMs simultaneously, thus dramatically reducing storage requirements. The greatest benefit is that you manage one desktop image for multiple users — you have guaranteed consistency across the desktop pool, and updates and patches are applied to one common use instance. The provisioning server acts as a "clever" file server, sharing a VHD format virtual disk, the workstations mount the .vhd file as their hard disk (see Figure 1.4).

    Virtual applications are then "delivered" into the user's desktop based on their user credentials. These applications can be installed dynamically, and can integrate user-installed applications. Virtual Profiles then inject the users' application and environment settings. The virtual desktop is then delivered to the end point over a presentation layer protocol. High Definition User Experience (HDX) includes the Citrix ICA protocol and the other technologies built around ICA to connect peripherals and deliver content to the end point.


    This book has been structured in such a way that you could run a XenDesktop project by simply following the chapters one by one. The "step-by-step" approach to the installation and configuration sections is meant to give you, the implementer, the information and the visual cues of the dialog boxes to successfully perform the implementation. We have tried to arrange the information — as far as possible — in such a way that you can omit sections not relevant to your project. The scope of every project is different, but we hope this gives you a basic framework from which you can extrapolate your own project.

    "User profiling" will normally precede a project of this nature. In almost every company, there will be a mix of technologies used to cater to the different needs of different groups of users. This book presumes that either "user profiling" has already been done, or that your proof of concept environment will highlight the groups of users that it would benefit the business to move onto virtual desktops.

    Chapter Two

    Installation of the Broker — Desktop Delivery Controller


    • How the Desktop Delivery Controller Works

    • DDC Installation

    • Active Directory Integration


    The Desktop Delivery Controller (DDC) is the core technology used to couple the XenDesktop components together. The DDC is effectively the traffic controller, directing the user to their assigned desktop based on their user credentials (see Figure 2.1).

    The XenDesktop technology has drawn from the Citrix XenApp technologies. In the context of XenApp, the users are mapped to assigned applications, whereas in XenDesktop, they are mapped to assigned Desktop Groups. The most notable difference is that the components being assigned are not resident on the machines doing the brokering. The Citrix "Farm" mechanism remains largely the same, but the portion being "presented" to the users — a Windows desktop operating system — had to be rebuilt. The Virtual Desktop Agent components are designated as "PortICA" in some of the registry settings. This is because the ICA (Independent Computing Architecture) protocol was "ported" from Windows server to Windows desktop operating systems. It may be useful — for those familiar with XenApp — to think of it in terms of the XenApp management components remain on the DDC, but the ICA stack has been moved to a Windows XP, Windows Vista, or Windows 7 workstations.

    Multiple virtual desktops are installed on a physical server; these virtual desktops have a Virtual Desktop Agent installed on them. The Virtual Desktop Agent registers with the DDC.

    Figures 2.2 and 2.3 illustrate how the components interact.

    1. The Virtual Desktop Agent queries Active Directory for the DDC address.

    2. The Virtual Desktop Agent then registers the virtual desktop as available for use.

    3. The user requests a virtual desktop from the DDC.

    4. The controller returns the connection information.

    5. The virtual desktop launches to the user.

    It is important to note that the DDC brokers the connection, but once the connection is established, the communication is directly between the user's device and the virtual desktop. If the DDC is rebooted, it would not affect the connected sessions.

    A single DDC can broker literally thousands of virtual desktops. A recent whitepaper cites scalability testing of three DDCs managing a farm of 6000 virtual desktops. (4vCPU 4GB RAM per controller), two of the servers were configured to perform registrations, one to act as only a farm master. Most environments will include at least two DDCs, providing load balancing and failover.

    The very simplest proof of concept can be conducted with two PCs — one configured with a desktop operating system and the other configured with Windows Server 2003 and the DDC software. This can be a quick and effective way of demonstrating the performance when connecting to a remote workstation. The workstation could be a physical machine or a VM.


    Important Considerations

    1. The user account performing the installation must be a local administrator on the server. If an enterprise database is being used, it should also be db_owner of the database.

    2. Only Windows Server 2003 is supported for the DDC. The version can be SP2 or R2, (System Center Virtual Machine Manager [SCVMM] requires R2 for Hyper-V integration). Both x86 and 64-bit versions are supported. This will change with the next release, but not yet at the time of writing.

    3. Terminal Services in application mode must be installed — otherwise, you will be prompted for the Windows 2003 CD during installation to add this component.

    The DDC is based on the XenApp software, and this is a legacy link to XenApp.

    4. IIS must be installed — otherwise, you will be prompted for the Windows 2003 CD during installation to add this component.

    5. Install NET 3.5 SP1 and all the latest Windows Updates.

    6. Install JRE 1.5.0_15 — this can be found in the Support folder off the root of the XenDesktop Media.

    The Microsoft Updates to the .NET Framework have introduced significant scalability improvements.

    For Hyper-V only,

    7. Install the SCVMM Administrator Console on the server before installing the Citrix DDC software. If the SCVMM Administrator Console isn't installed, only the XenServer and VMware hypervisors are available for integration.

    SQL Express or an Access format database is sufficient for a proof of concept. A pilot or production should make use of an Enterprise Database, which can be easily backed up and restored as required.

    8. Microsoft SQL 2000 or 2005, or Oracle 11 g Release 1 — Microsoft SQL 2005 is recommended. Microsoft SQL 2008 was not officially supported at the time of writing — it does indeed work with the backward compatibility pack, so I would be comfortable using it for a proof of concept system, but not for a production system.

    9. The installer user account must have db_owner rights to the SQL database. We recommend a service account be used for this purpose in production environments.

    Provisioning server requires Microsoft SQL 2005 or Microsoft SQL 2008 if you wish to use the same database server; at the time of writing, we would recommend Microsoft SQL 2005. Check the Citrix Web site for the latest support, the latest XenApp release is geared toward SQL 2008, and XenDesktop support may well be included by the time this goes to press.


    To obtain the software, log in to and select Downloads | XenDesktop.

    The XDS_4_0_0_dvd.ISO file is more than 1 GB in size, so this is definitely something you want to start downloading the day before your implementation.

    If IIS is not installed, you will be prompted for the Windows Server 2003 disk and IIS will be installed. By default, the Setup program will install Web Interface on every DDC.

    DDC Installation — Step by Step

    1. Mount the XenDesktop 4 DVD on your server.

    2. The DVD should autorun, if it doesn't, click autorun.exe in the root of the DVD.

    3. Click Install Server Components (see Figure 2.4).

    4. Change the radio button to accept the license agreement, and click Next (see Figure 2.5).
