Device Applications of Silicon Nanocrystals and Nanostructures

by Nobuyoshi Koshida (Editor)

Overview

Recent developments in the technology of silicon nanocrystals and silicon nanostructures, where quantum-size effects are important, are systematically described including examples of device applications. Due to the strong quantum confinement effect, the material properties are freed from the usual indirect- or direct-bandgap regime, and the optical, electrical, thermal, and chemical properties of these nanocrystalline and nanostructured semiconductors are drastically changed from those of bulk silicon. In addition to efficient visible luminescence, various other useful material functions are induced in nanocrystalline silicon and periodic silicon nanostructures. Some novel devices and applications, in fields such as photonics (electroluminescence diode, microcavity, and waveguide), electronics (single-electron device, spin transistor, nonvolatile memory, and ballistic electron emitter), acoustics, and biology, have been developed by the use of these quantum-induced functions in ways different from the conventional scaling principle for ULSI.

Product Details

ISBN-13:	9780387786889
Publisher:	Springer US
Publication date:	12/18/2008
Series:	Nanostructure Science and Technology
Edition description:	2009
Pages:	344
Product dimensions:	6.10(w) x 9.25(h) x 0.03(d)

Table of Contents

Si-Rich Dielectrics for Active Photonic Devices.- Nanocrystalline Si EL Devices.- Surface and Superlattice.- Optical Gain and Lasing in Low Dimensional Silicon: The Quest for an Injection Laser.- Silicon Single-Electron Devices.- Room Temperature Silicon Spin-Based Transistors.- Electron Transport in Nanocrystalline Silicon.- Silicon Nanocrystal Nonvolatile Memories.- Nanocrystalline Silicon Ballistic Electron Emitter.- Porous Silicon Optical Label-Free Biosensors.- Ultrasonic Emission from Nanocrystalline Porous Silicon.
