Electromagnetic Analysis Using Transmission Line Variables (2nd Edition) / Edition 2

Hardcover (Print)
Buy New
Buy New from BN.com
$123.49
Used and New from Other Sellers
Used and New from Other Sellers
from $128.11
Usually ships in 1-2 business days
(Save 7%)
Other sellers (Hardcover)
  • All (2) from $128.11
  • New (1) from $128.11
  • Used (1) from $124.72

More About This Textbook

Overview

This book employs a relatively new method for solving electromagnetic problems, one which makes use of a transmission line matrix (TLM). The propagation space is imagined to be filled with this matrix. The propagating fields and physical properties are then mapped onto the matrix. Mathematically, the procedures are identical with the traditional numerical methods; however, the interpretation and physical appeal of the transmission line matrix are far superior. Any change in the matrix has an immediate physical significance. What is also very important is that the matrix becomes a launching pad for many improvements in the analysis, using more modern notions of electromagnetic waves. Eventually, the purely mathematical techniques will probably give way to the transmission line matrix method.

Major revisions occur in chapters IV and VII in this second edition. The revised chapters now present an up-to-date and concise treatment on plane wave correlations and decorrelations, providing new and more accurate simulations for solving transient electromagnetic problems. The revisions also take into account semiconductors with arbitrary dielectric constant, using much smaller cell size, and thus extending the range of applicability and improving accuracy.

Note on figure:

The figure shows a transmission line matrix (TLM) grid used to solve problems in electromagnetics and other areas of physics. The grid consists of scattering nodes (circles) which are connected by transmission lines, in which the electromagnetic waves flow. The arrows represent forward and backward waves in each transmission line. The above grid may be used instead of standard numerical methods.

Read More Show Less

Product Details

  • ISBN-13: 9789814287487
  • Publisher: World Scientific Publishing Company, Incorporated
  • Publication date: 8/31/2010
  • Edition number: 2
  • Pages: 492
  • Product dimensions: 6.10 (w) x 9.00 (h) x 1.20 (d)

Table of Contents

Preface vii

1 Introduction to Transmission Lines and Their Application to Electromagnetic Phenomena 1

1.1 Simple Experimental Example 4

1.2 Examples of Impulse Sources 6

1.3 Model Outline 9

1.4 Application of Model to Small Node Resistance 17

1.5 Transmission Line Theory Background 17

1.6 Initial Conditions of Special Interest 22

One Dimensional TLM Analysis. Comparison with Finite Difference Method 24

1.7 TLM Iteration Method 24

1.8 Reverse TLM Iteration 25

1.9 Derivation of Scattering Coefficients For Reverse Iteration 29

1.10 Complete TLM Iteration (Combining Forward and Reverse Iterations) 31

1.11 Finite Difference Method. Comparison with TLM Method 32

Two Dimensional TLM Analysis. Comparison with Finite Difference Method 33

1.12 Boundary Conditions at 2D Node 35

1.13 Static Behavior about 2D Node 37

1.14 Non-static Example: Wave Incident on 2D node 38

1.15 Integral Rotational Properties of Field about the Node 42

1.16 2D TLM Iteration Method for Nine Cell Core Matrix 46

1.17 2D Finite Difference Method. Comparison with TLM Method 50

1.18 Final Comments: Inclusion of Time Varying Signals and Phase Coherence 56

Appendices 57

App. 1A.1 Effect of Additional Paths on Weighing Process 57

App. 1A.2 Novel Applications of TLM Method: Description of Neurological Activity Using the TLM Method 60

2 Notation and Mapping of Physical Properties 65

2.1 1D Cell Notation and Mapping of Conductivity and Field 67

2.2 Neighboring 1D Cells with Unequal Impedance 70

2.3 2D Cell Notation, Mapping of Conductivity and Field 72

2.4 Simultaneous Conductivity Contributions 80

2.5 3D Cell Notation, Mapping of Conductivity and Field 82

Other Node Controlled Properties 88

2.6 Node Control of 2D Scattering Coefficients Due to Finite Node Resistance 89

2.7 Signal Gain 90

2.8 Signal Generation. Use of Node Coupling 91

2.9 Mode Conversion 94

Example of Mapping: Node Resistance in Photoconductive Semiconductor 95

2.10 Semiconductor Switch Geometry (2D) 95

2.11 Node Resistance Profile in Semiconductor 98

3 Scattering Equations 101

3.1 1D Scattering Equation 101

3.2 2D Scattering Equations 104

3.3 Effect of Symmetry on Scattering Coefficients 113

3.4 3D Scattering Equations: Coplanar Scattering 116

General Scattering, Including Scattering Normal to Propagation Plane 124

3.5 Simple 3D Equivalent TLM Circuit 125

3.6 Quasi-Coupling 126

3.7 Neglect of Quasi-Coupling 127

3.8 Simple Quasi-Coupling Circuit. First Order Approximation 129

3.9 Correction to Quasi-Coupling Circuit: Second Order Approximation 133

3.10 Calculation of Load Impedance with Quasi-Coupling 136

3.11 Small Coupling Approximation of Second Order Quasi-Coupling 138

3.12 General 3D Scattering Process Using Cell Notation 140

3.13 Complete Iterative Equations 150

3.14 Contribution of Electric and Magnetic Fields to the Total Energy 153

Plane Wave Behavior 154

3.15 Response of 2D Cell Matrix to Input Plane Wave 154

3.16 Response of 2D Cell Matrix to Input Waves with Arbitrary Amplitudes 163

3.17 Response of 3D Cell Matrix to Input Plane Wave 164

3.18 Final Comments of Uniform Waves versus Plane Waves 167

Appendices 168

App. 3A.1 Consistency of 3D Circuit with the TLM Static Solutions 168

App. 3A.2 3D Scattering Coefficients, Without Quasi-Coupling in Terms of Circuit Parameters 169

App. 3A.3 3D Scattering Coefficients with Both Coplanar and Aplanar Contributions into Unit Cell Lines (yz and zx Planes) 172

App. 3A.4 3D Scattering Equations: with Both Coplanar and Aplanar Contributions into Unit Cell Lines (yz and zx Planes) 174

4 Corrections for Plane Waves and Grid Anisotropy Effects 177

4.1 Partition of TLM Waves into Component Waves 177

4.2 Scattering Corrections for 2D Plane Waves: Plane Wave Correlations Between Cells 179

4.3 Changes to 2D Scattering Coefficients 186

Corrections to Plane Wave Correlations 188

4.4 Correlation of Waves in Adjoining Media with Differing Dielectric Constants 188

4.5 Modification of Wave Correlation Adjacent a Conducting Boundary 190

Decorrelation Processes 192

4.6 Decorrelation Due to Sign Disparity of Plane and Symmetric Waves 192

4.7 Related Scattering Criteria and Sign Conditions for Removal of the Sign Disparity 196

4.8 Minimal Solution Using Differing Decorrelation Factors to Remove Sign Disparities 198

4.9 Decorrelation of Forward and Backward Plane Waves with Same Polarity in Neighboring Series TLM Lines Without Losses 202

4.10 Decorrelation of Forward and Backward Plane Waves with the Same Polarity Occupying the Same TLM Line 205

4.11 Decorrelation Treatment at Boundary Interfaces 208

4.12 Comments on Interaction of Plane Wave Front with a Half-Infinite Conducting Plane 210

4.13 Summary of Correlation/Decorrelation Processes 212

Treatment of Grid Orientation Effects 213

4.14 Dependence of Wave Energy Dispersal on Grid Orientation for Symmetric and Plane Waves 213

4.15 Selection of Grid for Plane Waves 216

4.16 Transformation Properties between Grids 217

4.17 Possible Mini-Plane Wave Fronts Associated with Each Cell. Plane Wave Partitioning 218

Grid(s) Selection. Propagation Vector Independence 220

4.18 Transformation of Fields to Principal Grid 220

4.19 Incorporation of Symmetric Waves 221

4.20 Iteration Method Using Principal Grid Transformations 222

4.21 Treatment of Separate TLM Correlated Wave Sources 224

4.22 Final Comments 226

Appendices 226

App. 4A.1 3D Scattering Corrections of Plane Waves (Plane Wave Correlations) 226

App. 4A.2 Consistency of Plane Wave Correlations with a Simple Quantum Mechanical Model 229

5 Boundary Conditions and Dispersion 233

5.1 Dielectric-Dielectric Interface 234

Node Coupling: Nearest Node and Multi-Coupled Node Approximations 238

5.2 Nearest Nodes for 1D Interface 241

5.3 Nearest Nodes at 2D Interface 242

5.4 Truncated Cells and Oblique Interface 244

5.5 Cell Index Notation at a Dielectric Interface Used in Simulations 245

5.6 Simplified Iteration Neglecting the Nearest Node Approximation 247

5.7 Non-Uniform Dielectric. Use of Cluster Cells 248

Other Boundary Conditions 251

5.8 Dielectric - Open Circuit Interface 251

5.9 Dielectric - Conductor Interface 252

5.10 Input/Output Conditions 254

5.11 Composite Transmission Line 256

5.12 Determination of Initial Static Field by TLM Method 257

Dispersion 260

5.13 TLM Methods for Treating Dispersion 260

5.14 Dispersion Sources 262

5.15 Dispersion Example 262

5.16 Propagation Velocity Dispersion 265

5.17 Node Resistance Dispersion 266

5.18 Anomalous Dispersion 267

Incorporation of Dispersion into TLM Formulation 268

5.19 Dispersion Approximations 268

5.20 Outline of Dispersion Calculation Using the TLM Method 269

5.21 One Dimensional Dispersion Iteration 269

5.22 Initial Conditions with Dispersion Present 280

5.23 Stability of Initial Profiles with Dispersion Present 281

5.24 Replacement of Non-uniform Field in Cell with Effective Uniform Field 284

Appendix 284

App. 5A.1 Specification of Input/Output Node Resistance to Eliminate Multiple Reflections 284

6 Cell Discharge Properties and Integration of Transport Phenomena into the Transmission Line Matrix 287

6.1 Charge Transfer between Cells 288

6.2 Relationship between Field and Cell Charge 291

6.3 Dependence of Conductivity on Carrier Properties 295

Integration of Carrier Transport Using TLM Notation. Changes in Cell Occupancy and Its Effect on the TLM Iteration 296

6.4 General Continuity Equations 296

6.5 Carrier Generation Due to Light Activation 296

6.6 Carrier Generation Due to Avalanching: Identical Hole and Electron Drift Velocities 297

6.7 Avalanching with Differing Hole and Electron Drift Velocities 300

6.8 Two Step Generation Process 303

6.9 Recombination 304

6.10 Limitations of Simple Exponential Recovery Model 306

6.11 Carrier Drift 307

6.12 Cell Charge Iteration. Equivalence of Drift and Inter-Cell Currents Using TLM Notation 310

6.13 Carrier Diffusion 315

6.14 Frequency of Transport Iteration 317

6.15 Total Contribution to Changes in Carrier Cell Occupancy 318

7 Description of TLM Iteration 321

7.1 Specification of Geometry 324

7.2 Use of TLM Matrix 326

7.3 Various Regions which Incorporate Plane Wave Correlation/Decorrelation (PWC Effects) into the Iteration 329

7.4 Simplified Decorrelation Procedure Used for Simulations in Chapter VII 330

7.5 Description of Inputs, Arrays, and Initial Conditions 336

7.6 Plane Wave Correllation (PWC) Inputs 338

7.7 Iteration Outline 339

7.8 Node Resistance R(n,m) Changes. Use of Light Activation 340

Symmetric Scattering Simulations 345

7.9 Symmetric Field Evolution with and without Node Activation 345

PWC Simulations. Comparison of PWC and Symmetric Results 256

7.10 Comparison of Output Waveforms and Static Profiles for Symmetric and PWC Simulations 356

7.11 Comparison of Forward and Backward Waves when Using Wave Correlation 362

7.12 Risetime and Alternating Field Effects in the Guided Region 364

7.13 Field Profile Evolution during Transient Charge-up Phase 366

7.14 Effect of Load Mismatch on Output and Field Profile 370

7.15 Node Recovery and its Effect on Output Pulse and Field Profile 370

7.16 Effects of Risetime on Conductivity 374

7.17 Partial Activation of Nodes and Effect on Profiles and Output 375

7.18 Cell Charge Following Recovery 377

7.19 Role of TLM Waves at Charged Boundary 380

7.20 Incorporation of 3D Scattering Parameters into 2D Iteration. Application to Magnetostatic Solutions 381

7.21 Summary: Comparison of PWC and Symmetric Simulation Results 383

Appendices 385

7A.1 Outline Discussion of Program Statements for Activated Semiconductor Switch 385

7A.2 Program Statements for Optically Activated Semiconductor Switch 397

7A.3 Matching Node Resistors for Input & Output Sections 437

7A.4 Field Decay in Semiconductor Using the TLM Formulation 438

8 Spice Solutions 441

8.1 Photoconductive/Avalanche Switch 441

8.2 Traveling Wave Marx Generator 445

8.3 Traveling Marx Wave in a Layered Dielectric 450

Pulse Transformation and Generation Using Non-Uniform Transmission Lines 451

8.4 Use of Cell Chain to Simulate Pulse Transformer 452

8.5 Pulse Transformer Simulation Results 455

8.6 Pulse Source Using Non-Uniform TLM Lines (Switch at Output) 456

8.7 Radial Pulse Source (Switch at Output) 458

8.8 Pulse Sources with Gain (PFXL Sources) 459

Darlington Pulser 466

8.9 TLM Formulation of Darlington Pulser 469

8.10 SPICE Simulation of Lossy Darlington Pulser 470

Appendices 470

8A.1 Introduction To SPICE Format 470

8A.2 Discussion of Format for Photoconductive Switch 470

8A.3 TLM Analysis of Leading Edge Pulse in a Transformer 477

8A.4 TLM Analysis of Leading Edge Wave in PFXL 480

Biography of Maurice Weiner 487

Index 489

Read More Show Less

Customer Reviews

Be the first to write a review
( 0 )
Rating Distribution

5 Star

(0)

4 Star

(0)

3 Star

(0)

2 Star

(0)

1 Star

(0)

Your Rating:

Your Name: Create a Pen Name or

Barnes & Noble.com Review Rules

Our reader reviews allow you to share your comments on titles you liked, or didn't, with others. By submitting an online review, you are representing to Barnes & Noble.com that all information contained in your review is original and accurate in all respects, and that the submission of such content by you and the posting of such content by Barnes & Noble.com does not and will not violate the rights of any third party. Please follow the rules below to help ensure that your review can be posted.

Reviews by Our Customers Under the Age of 13

We highly value and respect everyone's opinion concerning the titles we offer. However, we cannot allow persons under the age of 13 to have accounts at BN.com or to post customer reviews. Please see our Terms of Use for more details.

What to exclude from your review:

Please do not write about reviews, commentary, or information posted on the product page. If you see any errors in the information on the product page, please send us an email.

Reviews should not contain any of the following:

  • - HTML tags, profanity, obscenities, vulgarities, or comments that defame anyone
  • - Time-sensitive information such as tour dates, signings, lectures, etc.
  • - Single-word reviews. Other people will read your review to discover why you liked or didn't like the title. Be descriptive.
  • - Comments focusing on the author or that may ruin the ending for others
  • - Phone numbers, addresses, URLs
  • - Pricing and availability information or alternative ordering information
  • - Advertisements or commercial solicitation

Reminder:

  • - By submitting a review, you grant to Barnes & Noble.com and its sublicensees the royalty-free, perpetual, irrevocable right and license to use the review in accordance with the Barnes & Noble.com Terms of Use.
  • - Barnes & Noble.com reserves the right not to post any review -- particularly those that do not follow the terms and conditions of these Rules. Barnes & Noble.com also reserves the right to remove any review at any time without notice.
  • - See Terms of Use for other conditions and disclaimers.
Search for Products You'd Like to Recommend

Recommend other products that relate to your review. Just search for them below and share!

Create a Pen Name

Your Pen Name is your unique identity on BN.com. It will appear on the reviews you write and other website activities. Your Pen Name cannot be edited, changed or deleted once submitted.


Your Pen Name can be any combination of alphanumeric characters (plus - and _), and must be at least two characters long.

Continue Anonymously

    If you find inappropriate content, please report it to Barnes & Noble
    Why is this product inappropriate?
    Comments (optional)
