Introduction to Nanotechnology / Edition 1

Hardcover (Print)
Rent from
(Save 67%)
Est. Return Date: 03/29/2015
Buy Used
Buy Used from
(Save 28%)
Item is in good condition but packaging may have signs of shelf wear/aging or torn packaging.
Condition: Used – Good details
Used and New from Other Sellers
Used and New from Other Sellers
from $40.40
Usually ships in 1-2 business days
(Save 71%)
Other sellers (Hardcover)
  • All (11) from $40.40
  • New (4) from $74.00
  • Used (7) from $40.40
Sort by
Page 1 of 1
Showing 1 – 3 of 4
Note: Marketplace items are not eligible for any coupons and promotions
Seller since 2008

Feedback rating:



New — never opened or used in original packaging.

Like New — packaging may have been opened. A "Like New" item is suitable to give as a gift.

Very Good — may have minor signs of wear on packaging but item works perfectly and has no damage.

Good — item is in good condition but packaging may have signs of shelf wear/aging or torn packaging. All specific defects should be noted in the Comments section associated with each item.

Acceptable — item is in working order but may show signs of wear such as scratches or torn packaging. All specific defects should be noted in the Comments section associated with each item.

Used — An item that has been opened and may show signs of wear. All specific defects should be noted in the Comments section associated with each item.

Refurbished — A used item that has been renewed or updated and verified to be in proper working condition. Not necessarily completed by the original manufacturer.

Comes with free delivery confirmation. Serving since 2003. We appreciate you and value your business. In stock compared to competitors who drop ship. Great book!

Ships from: Rochester, MN

Usually ships in 1-2 business days

  • Canadian
  • International
  • Standard, 48 States
  • Standard (AK, HI)
  • Express, 48 States
  • Express (AK, HI)
Seller since 2008

Feedback rating:


Condition: New
Brand New, Perfect Condition, Please allow 4-14 business days for delivery. 100% Money Back Guarantee, Over 1,000,000 customers served.

Ships from: Westminster, MD

Usually ships in 1-2 business days

  • Canadian
  • International
  • Standard, 48 States
  • Standard (AK, HI)
Seller since 2008

Feedback rating:


Condition: New
0471079359 Brand New. Exact book as advertised. Delivery in 4-14 business days (not calendar days). We are not able to expedite delivery.

Ships from: Romulus, MI

Usually ships in 1-2 business days

  • Canadian
  • International
  • Standard, 48 States
  • Standard (AK, HI)
Page 1 of 1
Showing 1 – 3 of 4
Sort by


This self-confessed introduction provides technical administrators and managers with a broad, practical overview of the subject and gives researchers working in different areas an appreciation of developments in nanotechnology outside their own fields of expertise.

Read More Show Less

Editorial Reviews

From the Publisher
"…recommended for research scientists." (IEEE Circuits and Devices, July/August 2005)

"...a very nice reference a solid overview of the topics and techniques…" (MRS Bulletin, May 2005)

"...a unique text for exploration of nanotechnology basics..." (IEEE Engineering in Medicine and Biology Medicine, March/April 2005)

"The two authors working together have maintained a consistent perspective and level throughout the book." (Physics Today, September 2004)

"…well written and nicely illustrated…offers a large amount of useful information to those who want to be introduced to the nanotechnologies…" (Clinical Chemistry, Vol. 50, No. 2, May 2004)

"The book has achieved its goal of providing a summary and commentary on this subject." (JOM, February 26, 2004)

"…the authors have achieved their aims and have hit the right tone and level of treatment…should also be suitable for advanced students…who are interested in the field…" (Angewandte Chemie International Edition, 2004/43)

"…a fascinating overview of nanotechnology and its applications. It offers a complete picture of the diversity of the technology's applications." (International Journal of General Systems, December 2003)

"…nicely designed, highly readable, and stylistically coherent…a superb addition to an already first-class lineup of contemporary textbooks on nanotechnology…" (Annals of Biomedical Engineering, Issue 32:02)

" introduction and overview of this innovative and increasingly important area of research..." (Materials Evaluation, August 2003)

"...wonderful introductory invaluable interdisciplinary look at the science of miniaturization and mesoscopic important resource for technical administrators and managers, as well as students and individuals..." (Polymer News)

“ excellent introduction to nanotechnology, especially for researchers who do not currently work in the field...provides a fantastic overview of nanotechnology and would appeal to anyone wanting to learn more about this exciting area...a great book...” (IEEE Electrical Insulation Magazine)

Read More Show Less

Product Details

  • ISBN-13: 9780471079354
  • Publisher: Wiley
  • Publication date: 5/31/2003
  • Edition description: New Edition
  • Edition number: 1
  • Pages: 400
  • Product dimensions: 6.44 (w) x 9.33 (h) x 1.00 (d)

Meet the Author

CHARLES P. POOLE Jr., PhD, a professor emeritus in the Department of Physics and Astronomy at the University of South Carolina is a member of the USC nanotechnology center.

FRANK J. OWENS, PhD, is a senior research scientist of the U.S. Army's Armament Research, Development, and Engineering Center, and a professor of physics in the graduate school of Hunter College of the City University of New York.
Both authors are Fellows of the American Physical Society.

Read More Show Less

Read an Excerpt

Introduction to Nanotechnology

By Charles P. Poole, Jr. Frank J. Owens

John Wiley & Sons

Copyright © 2003 John Wiley & Sons, Inc.
All right reserved.

ISBN: 0-471-07935-9

Chapter One


The prefix nano in the word nanotechnology means a billionth (1 x [10.sup.-9]). Nanotechnology deals with various structures of matter having dimensions of the order of a billionth of a meter. While the word nanotechnology is relatively new, the existence of functional devices and structures of nanometer dimensions is not new, and in fact such structures have existed on Earth as long as life itself. The abalone, a mollusk, constructs very strong shells having iridescent inner surfaces by organizing calcium carbonate into strong nanostructured bricks held together by a glue made of a carbohydrate-protein mix. Cracks initiated on the outside are unable to move through the shell because of the nanostructured bricks. The shells represent a natural demonstration that a structure fabricated from nanoparticles can be much stronger. We will discuss how and why nanostructuring leads to stronger materials in Chapter 6.

It is not clear when humans first began to take advantage of nanosized materials. It is known that in the fourth-century A.D. Roman glassmakers were fabricating glasses containing nanosized metals. An artifact from this period called the Lycurgus cup resides in the British Museum inLondon. The cup, which depicts the death of King Lycurgus, is made from soda lime glass containing sliver and gold nanoparticles. The color of the cup changes from green to a deep red when a light source is placed inside it. The great varieties of beautiful colors of the windows of medieval cathedrals are due to the presence of metal nanoparticles in the glass.

The potential importance of clusters was recognized by the Irish-born chemist Robert Boyle in his Sceptical Chymist published in 1661. In it Boyle criticizes Aristotle's belief that matter is composed of four elements: earth, fire, water, and air. Instead, he suggests that tiny particles of matter combine in various ways to form what he calls corpuscles. He refers to "minute masses or clusters that were not easily dissipable into such particles that composed them."

Photography is an advanced and mature technology, developed in the eighteenth and nineteenth centuries, which depends on production of silver nanoparticles sensitive to light. Photographic film is an emulsion, a thin layer of gelatin containing silver halides, such as silver bromide, and a base of transparent cellulose acetate. The light decomposes the silver halides, producing nanoparticles of silver, which are the pixels of the image. In the late eighteenth century the British scientists Thomas Wedgewood and Sir Humprey Davy were able to produce images using silver nitrate and chloride, but their images were not permanent. A number of French and British researchers worked on the problem in the nineteenth century. Such names as Daguerre, Niecpce, Talbot, Archer, and Kennet were involved. Interestingly James Clark Maxwell, whose major contributions were to electromagnetic theory, produced the first color photograph in 1861. Around 1883 the American inventor George Eastman, who would later found the Kodak Corporation, produced a film consisting of a long paper strip coated with an emulsion containing silver halides. He later developed this into a flexible film that could be rolled, which made photography accessible to many. So technology based on nanosized materials is really not that new.

In 1857 Michael Faraday published a paper in the Philosophical Transactions of the Royal Society, which attempted to explain how metal particles affect the color of church windows. Gustav Mie was the first to provide an explanation of the dependence of the color of the glasses on metal size and kind. His paper was published in the German Journal Annalen der Physik (Leipzig) in 1908.

Richard Feynman was awarded the Nobel Prize in physics in 1965 for his contributions to quantum electrodynamics, a subject far removed from nanotechnology. Feynman was also a very gifted and flamboyant teacher and lecturer on science, and is regarded as one of the great theoretical physicists of his time. He had a wide range of interests beyond science from playing bongo drums to attempting to interpret Mayan hieroglyphics. The range of his interests and wit can be appreciated by reading his lighthearted autobiographical book Surely You're Joking, Mr. Feynman. In 1960 he presented a visionary and prophetic lecture at a meeting of the American Physical Society, entitled "There is Plenty of Room at the Bottom," where he speculated on the possibility and potential of nanosized materials. He envisioned etching lines a few atoms wide with beams of electrons, effectively predicting the existence of electron-beam lithography, which is used today to make silicon chips. He proposed manipulating individual atoms to make new small structures having very different properties. Indeed, this has now been accomplished using a scanning tunneling microscope, discussed in Chapter 3. He envisioned building circuits on the scale of nanometers that can be used as elements in more powerful computers. Like many of present-day nanotechnology researchers, he recognized the existence of nanostructures in biological systems. Many of Feynman's speculations have become reality. However, his thinking did not resonate with scientists at the time. Perhaps because of his reputation for wit, the reaction of many in the audience could best be described by the title of his later book Surely You're Joking, Mr. Feynman. Of course, the lecture is now legendary among present-day nanotechnology researchers, but as one scientist has commented, "it was so visionary that it did not connect with people until the technology caught up with it."

There were other visionaries. Ralph Landauer, a theoretical physicist working for IBM in 1957, had ideas on nanoscale electronics and realized the importance that quantum-mechanical effects would play in such devices.

Although Feynman presented his visionary lecture in 1960, there was experimental activity in the 1950s and 1960s on small metal particles. It was not called nanotechnology at that time, and there was not much of it. Uhlir reported the first observation of porous silicon in 1956, but it was not until 1990 when room-temperature fluorescence was observed in this material that interest grew. The properties of porous silicon are discussed in Chapter 6. Other work in this era involved making alkali metal nanoparticles by vaporizing sodium or potassium metal and then condensing them on cooler materials called substrates. Magnetic fluids called ferrofluids were developed in the 1960s. They consist of nanosized magnetic particles dispersed in liquids. The particles were made by ballmilling in the presence of a surface-active agent (surfactant) and liquid carrier. They have a number of interesting properties and applications, which are discussed in Chapter 7. Another area of activity in the 1960s involved electron paramagnetic resonance (EPR) of conduction electrons in metal particles of nanodimensions referred to as colloids in those days. The particles were produced by thermal decomposition and irradiation of solids having positive metal ions, and negative molecular ions such as sodium and potassium azide. In fact, decomposing these kinds of solids by heat is one way to make nanometal particles, and we discuss this subject in Chapter 4. Structural features of metal nanoparticles such as the existence of magic numbers were revealed in the 1970s using mass spectroscopic studies of sodium metal beams. Herman and co-workers measured the ionization potential of sodium clusters in 1978 and observed that it depended on the size of the cluster, which led to the development of the jellium model of clusters discussed in Chapter 4.

Groups at Bell Laboratories and IBM fabricated the first two-dimensional quantum wells in the early 1970s. They were made by thin-film (epitaxial) growth techniques that build a semiconductor layer one atom at a time. The work was the beginning of the development of the zero-dimensional quantum dot, which is now one of the more mature nanotechnologies with commercial applications. The quantum dot and its applications are discussed in Chapter 9.

However, it was not until the 1980s with the emergence of appropriate methods of fabrication of nanostructures that a notable increase in research activity occurred, and a number of significant developments resulted. In 1981, a method was developed to make metal clusters using a high-powered focused laser to vaporize metals into a hot plasma. This is discussed in Chapter 4. A gust of helium cools the vapor, condensing the metal atoms into clusters of various sizes. In 1985, this method was used to synthesize the fullerene ([C.sub.60]). In 1982, two Russian scientists, Ekimov and Omushchenko, reported the first observation of quantum confinement, which is discussed in Chapter 9. The scanning tunneling microscope was developed during this decade by G. K. Binnig and H. Roher of the IBM Research Laboratory in Zürich, and they were awarded the Nobel Prize in 1986 for this. The invention of the scanning tunneling microscope (STM) and the atomic force microscope (AFM), which are described in Chapter 3, provided new important tools for viewing, characterizing, and atomic manipulation of nanostructures. In 1987, B. J. van Wees and H. van Houten of the Netherlands observed steps in the current-voltage curves of small point contacts. Similar steps were observed by D. Wharam and M. Pepper of Cambridge University. This represented the first observation of the quantization of conductance. At the same time T. A. Fulton and G. J. Dolan of Bell Laboratories made a single-electron transistor and observed the Coulomb blockade, which is explained in Chapter 9. This period was marked by development of methods of fabrication such as electron-beam lithography, which are capable of producing 10-nm structures. Also in this decade layered alternating metal magnetic and nonmagnetic materials, which displayed the fascinating property of giant magnetoresistance, were fabricated. The layers were a nanometer thick, and the materials have an important application in magnetic storage devices in computers. This subject is discussed in Chapter 7.

Although the concept of photonic crystals was theoretically formulated in the late 1980s, the first three-dimensional periodic photonic crystal possessing a complete bandgap was fabricated by Yablonovitch in 1991. Photonic crystals are discussed in Chapter 6. In the 1990s, Iijima made carbon nanotubes, and superconductivity and ferromagnetism were found in [C.sub.60] structures. Efforts also began to make molecular switches and measure the electrical conductivity of molecules. A field-effect transistor based on carbon nanotubes was demonstrated. All of these subjects are discussed in this book. The study of self-assembly of molecules on metal surfaces intensified. Self-assembly refers to the spontaneous bonding of molecules to metal surfaces, forming an organized array of molecules on the surface. Self-assembly of thiol and disulfide compounds on gold has been most widely studied, and the work is presented in Chapter 10.

In 1996, a number of government agencies led by the National Science Foundation commissioned a study to assess the current worldwide status of trends, research, and development in nanoscience and nanotechnology. The detailed recommendations led to a commitment by the government to provide major funding and establish a national nanotechnology initiative. Figure 1.1 shows the growth of U.S. government funding for nanotechnology and the projected increase due to the national nanotechnology initiative. Two general findings emerged from the study.

The first observation was that materials have been and can be nanostructured for new properties and novel performance. The underlying basis for this, which we discuss in more detail in later chapters, is that every property of a material has a characteristic or critical length associated with it. For example, the resistance of a material that results from the conduction electrons being scattered out of the direction of flow by collisions with vibrating atoms and impurities, can be characterized by a length called the scattering length. This length is the average distance an electron travels before being deflected. The fundamental physics and chemistry changes when the dimensions of a solid become comparable to one or more of these characteristic lengths, many of which are in the nanometer range. One of the most important examples of this is what happens when the size of a semiconducting material is in the order of the wavelength of the electrons or holes that carry current. As we discuss in Chapter 9, the electronic structure of the system completely changes. This is the basis of the quantum dot, which is a relatively mature application of nanotechnology resulting in the quantum-dot laser presently used to read compact disks (CDs). However, as we shall see in Chapter 9, the electron structure is strongly influenced by the number of dimensions that are nanosized.

If only one length of a three-dimensional nanostructure is of a nanodimension, the structure is known as a quantum well, and the electronic structure is quite different from the arrangement where two sides are of nanometer length, constituting what is referred to as a quantum wire. A quantum dot has all three dimensions in the nanorange. Chapter 9 discusses in detail the effect of dimension on the electronic properties of nanostructures. The changes in electronic properties with size result in major changes in the optical properties of nanosized materials, which is discussed in Chapter 8, along with the effects of reduced size on the vibrational properties of materials.


Excerpted from Introduction to Nanotechnology by Charles P. Poole, Jr. Frank J. Owens Copyright © 2003 by John Wiley & Sons, Inc.. Excerpted by permission.
All rights reserved. No part of this excerpt may be reproduced or reprinted without permission in writing from the publisher.
Excerpts are provided by Dial-A-Book Inc. solely for the personal use of visitors to this web site.

Read More Show Less

Table of Contents


1. Introduction.

2. Introduction to Physics of the Solid State.

3. Methods of Measuring Properties.

4. Properties of Individual Nanoparticles.

5. Carbon Nanostructures.

6. Bulk Nanostructured Materials.

7. Nanostructured Ferromagnetism.

8. Optical and Vibrational Spectroscopy.

9. Quantum Wells, Wires, and Dots.

10. Self-Assembly and Catalysis.

11. Organic Compounds and Polymers.

12. Biological Materials.

13. Nanomachines and Nanodevices.

Appendix A: Formulas for Dimensionality.

Appendix B: Tabulations of Semiconducting Material Properties.


Read More Show Less
