Rheology for Chemists: An Introduction

by J W Goodwin, R W Hughes

Overview

This book is a valuable resource for practitioners working in the field, and offers a comprehensive introduction for graduate and post graduates

Product Details

ISBN-13:	9781788018258
Publisher:	RSC
Publication date:	04/05/2019
Sold by:	Barnes & Noble
Format:	eBook
Pages:	276
File size:	4 MB

Read an Excerpt

Rheology for Chemists

An Introduction

---

By Jim W. Goodwin, Roy W. Hughes

The Royal Society of Chemistry

Copyright © 2000 The Royal Society of Chemistry
All rights reserved.
ISBN: 978-1-84755-183-2

---

CHAPTER 1

Introduction

The study of rheology is the study of the deformation of matter resulting from the application of a force. The type of deformation depends on the state of matter. For example, gases and liquids will flow when a force is applied, whilst solids will deform by a fixed amount and we expect them to regain their shape when the force is removed. In other words we are studying the 'handling properties of materials'. This immediately reminds us that we must consider solutions and dispersions and not simply pure materials. In fact, the utility of many of the materials we make use of every day is due to their rheological behaviour and many chemists are formulating materials to have a particular range of textures, flow properties, etc. or are endeavouring to control transport properties in a manufacturing plant. Interest in the textures of materials such as a chocolate mousse or a shower gel may be of professional interest to the chemist in addition to natural curiosity. How do we describe their textures quantitatively? What measurements should we make? What is the chemistry underlying the texture so that we may control it? All these questions make us focus on rheology.

The aim of this text is to enable the reader to gain an understanding of the physical origins of viscosity, elasticity and viscoelasticity. The route that we shall follow is to introduce the key concepts through physical ideas and analogues that are familiar to chemists and biologists. Ideas from chemical kinetics, and infrared and microwave spectroscopy are invariably covered in some depth in many science courses and so should aid the understanding of rheological processes. The mathematical content is kept to the minimum necessary to give us a quantitative description of a process, and we have taken care to make any manipulations as transparent as possible.

There are two important underlying ideas that we shall return to throughout this work. Firstly, we should be aware that intermolecular forces control the way in which materials behave. This is where the chemical nature is controlling the physical response. The second is the importance of the timescale of our observations, and here we may become aware of different physical responses if our experiments are carried out at different times. The link between the two arises through the structure that is the consequence of the forces and the timescale for changes by microstructural motion resulting from thermal or mechanical energy. What is so exciting about rheology is the insights that we can gain into the origins of the behaviour of a wide variety of systems in our everyday mechanical world.

1.1 DEFINITIONS

1.1.1 Stress and Strain

The stress is simply defined as the force divided by the area over which it is applied. Pressure is a compressive bulk stress. When we hang a weight on a wire, we are applying an extensional stress and when we slide a piece of paper over a gummed surface to reach the correct position, we are applying a shear stress. We will focus more strongly on this latter stress because most of our instruments are designed around this format. The units of stress are Pascals.

When a stress is applied to a material, a deformation will occur. In order to make calculations tractable, we define the strain as the relative deformation, i.e. the deformation per unit length. The length that we use is the one over which the deformation occurs. This is illustrated m Figures 1.1 and 1.2.

There are several features of note in Figures 1.1 and 1.2:

1. The elastic modulus is constant at small stresses and strains. This linearity gives us Hooke's Law, which states that the stress is directly proportional to the strain.

2. At high stresses and strains, non-linearity is observed. Strain hardening (an increasing modulus with increasing strain up to fracture) is normally observed with polymeric networks. Strain softening is observed with some metals and colloids until yield is observed.

3. We should recognise that stress and strain are tensor quantities and not scalars. This will not present any difficulties in this text but we should bear it in mind because the consequences can be both dramatic and useful. To illustrate the mathematical problem, we can think about what happens when we apply a strain to an element of our material. The strain is made up of three orthogonal components which can be further subdivided into three elements, each of which is lined up with one of our axes. This is shown in Figure 1.3.

Figures 1.2 and 1.3 show how, if we apply a simple shear strain, γ, in our rheometer this is formally made up of two equal components, γxy and γyx. By restricting ourselves to simple and well-defined deformations and flows, i.e. simple viscometric flows, most algebraic difficulties will be avoided but the exciting consequences will still be seen.

1.1.2 Rate of Strain and Flow

When a fluid system is studied by the application of a stress, motion is produced until the stress is removed. Consider two surfaces separated by a small gap containing a liquid, as illustrated in Figure 1.4. A constant shear stress must be maintained on the upper surface for it to move at a constant velocity, u. If we can assume that there is no slip between the surface and the liquid, there is a continuous change in velocity across the small gap to zero at the lower surface. Now in each second the displacement produced is x and the strain is

γ = x/z (1.1)

and us u - dx/dt, we can write the rate of strain as

dγ/dt = u/z (1.2)

The terms rate of strain, velocity gradient and shear rate are all used synonymously and Newton's dot is normally used to indicate the differential operator with respect to time. For large gaps the rate of strain will vary across the gap and so we should write

γ = du/dz (1.3)

When the plot of shear stress versus shear rate is linear, the liquid behaviour is simple and the liquid is Newtonian with the coefficient of viscosity, η, being the proportionality constant.

When a flow is used which causes an extension of a liquid, the resistance to this motion arises from the extensional viscosity, ηε, and the extension rate is ε. Extensional flows require an acceleration of the fluid as it thins and so steady flows are never achieved. This means that microstructural timescale is particularly important. Many practical applications involve extensional flows, frequently with a shear component. For example spraying, spreading and roller coating are common ways of applying products from the food, pharmaceutical, paint and printing industries. Although the analysis may be carried out as though the materials are continua with uniform properties, the control comes from an understanding of the role of molecular architecture and forces.

1.2 SIMPLE CONSTITUTIVE EQUATIONS

1.2.1 Linear and Non-linear Behaviour

It is easy to write down an algebraic relationship that describes the simpler forms of rheological behaviour. For example

for a Hookean solid σ = Gγ (1.4)

and a Newtonian liquid σ = ηγ (1.5)

These equations should fully describe the stress–strain–time relationship for the materials over the full range of response. However, the range over which such linear behaviour is observed is invariably limited. Usually large stresses and strains or short times cause deviations from Equations 1.4 or 1.5.

As the behaviour becomes more complicated, more parameters are required to fit the experimental curves. To illustrate this, consider two common equations used to describe the shear-thinning behaviour observed in viscometers. Figure 1.5 shows these two responses.

Figure 1.5a shows a steady shear-thinning response and the experimental points can be fitted to a simple equation:

σ = Acγn (1.6)

where the two fitting parameters are Ac, the 'consistency', and n, the 'power law index'. This equation is often presented in its viscosity form:

η = Acγn-1 (1.7)

Figure 1.5b shows the behaviour of a 'Bingham plastic' and the fitting equation is:

σ = η pγ + σB (1.8)

Here the fitting parameters are the slope of the line (the plastic viscosity, ηp) and the Bingham or dynamic yield stress (the intercept, σB). Other constitutive equations will be introduced later in this volume as appropriate.

1.2.2 Using Constitutive Equations

The first use that we can make of our constitutive equations is to fit and smooth our data and so enable us to discuss experimental errors. However, in doing this we have the material parameters from the model. Of course it is these that we need to record on our data sheets, as they will enable us to reproduce the experimental curves and we will then be able to compare the values from batch to batch of a product or formulation. This ability to collapse more or less complicated curves down to a few numbers is of great value whether we are engaged in the production of, the application of, or research into materials.

The corollary is that we should always keep in mind the experimental range. Extrapolation outside that range is unwise. This will become particularly clear when we discuss the yield phenomenon – an area of great interest in many practical situations. Whatever the origins claimed for these models, they all really stem from the phenomenological study of our materials and so our choice of which one to use should be based on the maximum utility and simplicity for the job in hand.

1.3 DIMENSIONLESS GROUPS

An everyday task in our laboratories is to make measurements of some property as a function of one or more parameters and to express our data graphically, or more compactly as an algebraic equation. To understand the relationships that we are exploring, it is useful to express our data as quantities that do not change when the units of measurement change. This immediately enables us to 'scale' the response. Let us take as an example the effect of temperature on reaction rate. The well-known Arrhenius equation gives us the variation

kr = A exp(-Ea/RT) (1.9)

Here kr is the rate of a reaction measured at temperature T, Ea is the activation energy and R is the gas constant. Now RT is the value of thermal energy and so the magnitude of the dimensionless group, (Ea/RT), immediately gives us a feel as to the importance of the activation process. For example, if Ea [much less than] RT, then the activation process will not slow the reaction rate significantly from the fastest possible rate A. On the other hand, if Ea [much greater than] RT, then the reaction rate will be very much slower than A. Mechanistically this reminds us of the Boltzmann energy distribution and stochastic processes. The dimensionless group, (Ea/RT), is known as the 'Arrhenius Group'.

Another example from chemical kinetics can be seen in the rate equation for first-order reactions. Here the equation relating the concentration of a species A at time t, [A](t), to the reaction time and the initial concentration, [A](00), is

[A](t) = [A](00)exp(-krt) (1.10)

The rate coefficient, kr has units of t-1 and so can equally well be thought of in terms of the characteristic time for the reaction to take place. Hence if krt [much greater than] 1, the reaction will be a long way towards completion, whereas if krt [much less than] 1, very little change will have occurred. Equation 1.10 describes the decay of radioactive elements and 1/kr could be considered as the characteristic time for the relaxation of the element from its active to its non-active state.

1.3.1 The Deborah Number

Maxwell introduced the idea of viscous flow as being the manifestation of the decay of elastically stored energy. If we follow this concept through we will see how a dimensionless group, the Deborah number, De, arises naturally. Let us consider a piece of matter in which all the molecules or particles (either small or large, it makes no difference) have had time to diffuse to some low energy state. Now if we instantaneously strain (deform) the material, we will store energy because the structure is perturbed and the molecules are in a higher energy state. As we hold the matter in this new shape, it becomes easier because the molecules diffuse until a low energy state equivalent to the initial one has been achieved, although the original shape has been lost, i.e. viscous flow has occurred. We can define the characteristic time it takes for this process to occur as the stress relaxation time, τ, of the material. Now the Deborah number is

De = τ/t (1.11)

The relaxation of the stress resulting from a step strain can be observed experimentally and we can see that it is the result of diffusive motion of the microstructural elements. Although we can have a mechanistic picture, what does this mean in terms of our measurements? We have the very striking result that our material classification must depend on the time t, i.e. the experimental or observation time. Hence, we can usefully classify material behaviour into three categories:

De [much greater than] De~O(1) De [much less than]
solid-like viscoelastic liquid-like

The most frequently quoted example to illustrate this behaviour is the children's toy 'Silly Putty', which is a poly(dimethyl siloxane) polymer. Pulled rapidly it shows brittle fracture like any solid but if pulled slowly it flows as a liquid. The relaxation time for this material is ~ 1 s. After t = 5 τ the stress will have fallen to 0.7% of its initial value so the material will have effectively 'forgotten' its original shape. That is, one could describe it as having a 'memory' of around 5 s (about that of a mackerel!). Many other materials in common use have relaxation times within an order of magnitude or so of 1 s. Examples are thickened detergents, personal care products and latex paints. This is of course no coincidence, and this timescale is frequently deliberately chosen by formulation adjustments. The reason is that it is in the middle of our, the human, timescale. Our nervous system responds over a timescale of 1 ms to 1ks and so, if a material has a relaxation time within that region, we will observe an 'interesting' or useful texture. Reiner pointed out that our observation time could be quite long with some materials, set concrete for example, and so ultimately our definition of solid-like can become one of practical rather than philosophic origin.

1.3.2 The Peclet Number

Although a mechanism for stress relaxation was described in Section 1.3.2, the Deborah number is purely based on experimental measurements, i.e. an observation of a bulk material behaviour. The Peclet number, however, is determined by the diffusivity of the microstructural elements, and is the dimensionless group given by the timescale for diffusive motion relative to that for convective or flow. The diffusion coefficient, D, is given by the Stokes–Einstein equation:

D = kBT/6πηoa (1.12)

where kB is the Boltzmann constant, ηo is the viscosity of the liquid medium, and a is the radius of the diffusing moiety – molecule or particle. This has dimensions of m2s-1. We can use Equation (1.12) to estimate the time taken for the diffusing moiety to move a characteristic distance. It makes sense to choose the radius as this distance and this gives us the Einstein–Smoluchowski equation:

ta = a2/D = 6πηoa/ kBT

and so

ta = 6πηoa3/kBT (1.13)

Now the characteristic time for shear flow is the reciprocal of the shear rate. This is the time taken for a cubic element of material to be transformed to a parallelogram with angles of 45° (i.e. the time for unit strain to be applied) as shown in Figure 1.6. The Péclet number can now be written:

Pe = 6πηoa3γ/kBT (1.14)

An interesting problem arises when we consider solutions or colloidal sols where the diffusing component is much larger in size than the solute molecules. In dilute systems Equation (l.14) would give an adequate value of the Péclet number but not so when the system becomes concentrated, i.e. the system itself becomes a condensed phase. The interactions between the diffusing component slow the motion and, as we shall see in detail in Chapter 3, increase the viscosity. The appropriate dimensionless group should use the system viscosity and not that of the medium and now becomes

Pe = 6πa3σ/kBT (1.15)

where the shear stress, σ = η[??], has been used to make a clear distinction from Equation (1.14). Of course for a simple system, cyclohexane in decane for example, Equations (l.14) and (1.15) would give the same result as the intermolecular interactions between the species are similar and the viscosity of a mixture is similar to that of the two components. We shall use Equation (1.15) throughout as this indicates the importance of the interactions.

1.3.3 The Reduced Stress

The reduced stress, σr was introduced by Krieger from a dimensional analysis and has the form:

σr = a3σ/kBT (1.16)

The similarity to the Péclet number is obvious but we should also bear in mind the relationship to the Deborah number. This becomes clear when we consider the fact that the mechanism of stress relaxation is due to the diffusion of the microstructural components. For slow deformation processes – the low Deborah number, low Péclet number, or low reduced stress limit – the rate at which the structural elements can rearrange is great enough that the structure has little or no perturbation from that found in the quiescent state. Viscous deformation then occurs. Now if the straining is rapid, relaxation cannot take place and energy is stored. If the deformation is continuous, the structure must yield and breaking or 'melting' is then observed.

(Continues...)

---

Excerpted from Rheology for Chemists by Jim W. Goodwin, Roy W. Hughes. Copyright © 2000 The Royal Society of Chemistry. Excerpted by permission of The Royal Society of Chemistry.
All rights reserved. No part of this excerpt may be reproduced or reprinted without permission in writing from the publisher.
Excerpts are provided by Dial-A-Book Inc. solely for the personal use of visitors to this web site.

---

Table of Contents

Chapter 1	Introduction	1
1.1	Definitions	2
1.1.1	Stress and Strain	2
1.1.2	Rate of Strain and Flow	4
1.2	Simple Constitutive Equations	5
1.2.1	Linear and Non-linear Behaviour	5
1.2.2	Using Constitutive Equations	6
1.3	Dimensionless Groups	7
1.3.1	The Deborah Number	8
1.3.2	The Peclet Number	9
1.3.3	The Reduced Stress	10
1.3.4	The Taylor Number	11
1.3.5	The Reynolds Number	12
1.4	Macromolecular and Colloidal Systems	13
1.5	References	14
Chapter 2	Elasticity: High Deborah Number Measurements	15
2.1	Introduction	15
2.2	The Liquid-Solid Transition	17
2.2.1	Bulk Elasticity	19
2.2.2	Wave Propagation	21
2.3	Crystalline Solids at Large Strains	24
2.3.1	Lattice Defects	25
2.4	Macromolecular Solids	28
2.4.1	Polymers - An Introduction	28
2.4.2	Chain Conformation	29
2.4.3	Polymer Crystallinity	34
2.4.4	Crosslinked Elastomers	38
2.4.5	Self-associating Polymers	39
2.4.6	Non-interactive Fillers	44
2.4.7	Interactive Fillers	47
2.4.8	Summary of Polymeric Systems	47
2.5	Colloidal Gels	49
2.5.1	Interactions Between Colloidal Particles	49
2.5.2	London-van der Waals' Interactions	50
2.5.3	Depletion Interactions	51
2.5.4	Electrostatic Repulsion	52
2.5.5	Steric Repulsion	54
2.5.6	Electrosteric Interactions	56
2.6	References	59
Chapter 3	Viscosity: Low Deborah Number Measurements	61
3.1	Initial Considerations	61
3.2	Viscometric Measurement	64
3.2.1	The Cone and Plate	65
3.2.2	The Couette or Concentric Cylinder	66
3.3	The Molecular Origins of Viscosity	70
3.3.1	The Flow of Gases	71
3.3.2	The Flow of Liquids	71
3.3.3	Density and Phase Changes	72
3.3.4	Free Volume Model of Liquid Flow	76
3.3.5	Activation Energy Models	78
3.4	Superfluids	79
3.5	Macromolecular Fluids	80
3.5.1	Colloidal Dispersions	80
3.5.2	Dilute Dispersions of Spheres	81
3.5.3	Concentrated Dispersions of Spheres	84
3.5.4	Charge Stabilised Dispersions	89
3.6	References	97
Chapter 4	Linear Viscoelasticity I. Phenomenological Approach	98
4.1	Viscoelasticity	98
4.2	Length and Timescales	99
4.3	Mechanical Spectroscopy	100
4.4	Linear Viscoelasticity	101
4.4.1	Mechanical Analogues	102
4.4.2	Relaxation Derived as an Analogue to First-Order Chemical Kinetics	104
4.4.3	Oscillation Response	107
4.4.4	Multiple Processes	112
4.4.5	A Spectral Approach To Linear Viscoelastic Theory	116
4.5	Linear Viscoelastic Experiments	120
4.5.1	Relaxation	121
4.5.2	Stress Growth	124
4.5.3	Anti-thixotropic Response	125
4.5.4	Creep and Recovery	126
4.5.5	Strain Oscillation	129
4.5.6	Stress Oscillation	131
4.6	Interrelationships Between the Measurements and the Spectra	132
4.6.1	The Relationship Between Compliance and Modulus	133
4.6.2	Retardation and Relaxation Spectrum	135
4.6.3	The Relaxation Function and the Storage and Loss Moduli	136
4.6.4	Creep and Relaxation Interrelations	137
4.7	Applications to the Models	137
4.8	Microstructural Influences on the Kernel	140
4.8.1	The Extended Exponential	141
4.8.2	Power law or the Gel Equation	142
4.8.3	Exact Inversions from the Relaxation or Retardation Spectrum	143
4.9	Non-shearing Fields and Extension	144
4.10	References	145
Chapter 5	Linear Viscoelasticity II. Microstructural Approach	146
5.1	Intermediate Deborah Numbers De [approximate] 1	146
5.2	Hard Spheres and Atomic Fluids	147
5.3	Quasi-hard Sphere Dispersions	149
5.3.1	Quasi-hard Sphere Phase Diagrams	150
5.3.2	Quasi-hard Sphere Viscoelasticity and Viscosity	155
5.4	Weakly Attractive Systems	159
5.5	Charge Repulsion Systems	168
5.6	Simple Homopolymer Systems	179
5.6.1	Phase Behaviour and the Chain Overlap in Good Solvents	180
5.6.2	Dilute Solution Polymers	187
5.6.3	Undiluted and Concentrated Nonentangled Polymers	191
5.6.4	Entanglement Coupling	193
5.6.5	Reptation and Linear Viscoelasticity	195
5.7	Polymer Network Structure	202
5.7.1	The Formation of Gels	202
5.7.2	Chemical Networks	204
5.7.3	Physical Networks	207
5.8	References	211
Chapter 6	Non-linear Responses	213
6.1	Introduction	213
6.2	The Phenomenological Approach	214
6.2.1	Flow Curves: Definitions and Equations	214
6.2.2	Time Dependence in Flow and the Boltzmann Superposition Principle	218
6.2.3	Yield Stress Sedimentation and Linearity	225
6.3	The Microstructural Approach--Particles	229
6.3.1	Flow in Hard Sphere Systems	230
6.3.2	The Addition of a Surface Layer	233
6.3.3	Aggregation and Dispersion in Shear	234
6.3.4	Weakly Flocculated Dispersions	237
6.3.5	Strongly Aggregated and Coagulated Systems	244
6.3.6	Long-range Repulsive Systems	250
6.3.7	Rod-like Particles	254
6.4	The Microstructural Approach--Polymers	259
6.4.1	The Role of Entanglements in Non-linear Viscoelasticity	260
6.4.2	Entanglement of Solution Homopolymers	263
6.4.3	The Reptation Approach	265
6.5	Novel Applications	272
6.5.1	Extension and Complex Flows	272
6.5.2	Uniaxial Compression Modulus	276
6.5.3	Deformable Particles	279
6.6	References	284
	Subject Index	286

Editorial Reviews

For practicing, graduate, and undergraduate chemists, Goodwin, with an Oregon company, and Hughes (U. of Bristol) introduces the origins of viscosity, elasticity, and viscoelasticity by explaining the key concepts through physical ideas and analogues that are familiar to chemists and biologists. They emphasize throughout that intermolecular forces control how materials behave and that the timescale of the observation is important. Distributed in the US by Springer Verlag. Annotation c. Book News, Inc., Portland, OR (booknews.com)

Booknews

""... well-suited for self-study by research workers and technologists, who, confronted with technical problems in this area, would like a straightforward introduction to the subject of rheology.""

"Chemical Educator

""... full of valuable insights and up-to-date information.""

"Chemistry in Britain
