The Student's Guide to VHDL / Edition 2

by Peter J. Ashenden

Overview

The Student's Guide to VHDL is a condensed edition of The Designer's Guide to VHDL, the most widely used textbook on VHDL for digital system modeling. The Student's Guide is targeted as a supplemental reference book for computer organization and digital design courses.Since publication of the first edition of The Student's Guide, the IEEE VHDL and related standards have been revised. The Designer's Guide has been revised to reflect the changes, so it is appropriate that The Student's Guide also be revised. In The Student's Guide to VHDL, 2nd Edition, we have included a design case study illustrating an FPGA-based design flow. The aim is to show how VHDL modeling fits into a design flow, starting from high-level design and proceeding through detailed design and verification, synthesis, FPGA place and route, and final timing verification. Inclusion of the case study helps to better serve the educational market. Currently, most college courses do not formally address the details of design flow. Students may be given informal guidance on how to proceed with lab projects. In many cases, it is left to students to work it out for themselves. The case study in The Student's Guide provides a reference design flow that can be adapted to a variety of lab projects.

Product Details

ISBN-13:	9781558608658
Publisher:	Elsevier Science
Publication date:	05/19/2008
Series:	Systems on Silicon
Edition description:	REV
Pages:	528
Product dimensions:	7.30(w) x 9.10(h) x 1.30(d)

About the Author

Peter J. Ashenden received his B.Sc.(Hons) and Ph.D. from the University of Adelaide, Australia. He was previously a senior lecturer in computer science and is now a Visiting Research Fellow at the University of Adelaide. His research interests are computer organization and electronic design automation. Dr. Ashenden is also an independent consultant specializing in electronic design automation (EDA). He is actively involved in IEEE working groups developing VHDL standards, is the author of The Designer's Guide to VHDL and The Student's Guide to VHDL and co-editor of the Morgan Kaufmann series, Systems on Silicon. He is a senior member of the IEEE and a member of the ACM.

Read an Excerpt

From Chapter 7: Packages and Use Clauses

...Subprograms in Package Declarations

Another kind of declaration that may be included in a package declaration is a subprogram declaration—either a procedure or a function declaration. This ability allows us to write subprograms that implement useful operations and to call them from a number of different modules. An important use of this feature is to declare subprograms that operate on values of a type declared by the package. This gives us a way of conceptually extending VHDL with new types and operations, so-called abstract data types.

An important aspect of declaring a subprogram in a package declaration is that we only write the header of the subprogram, that is, the part that includes the name and the interface list defining the parameters (and result type for functions). We leave out the body of the subprogram. The reason for this is that the package declaration, as we mentioned earlier, provides only the external view of the items it declares, leaving the implementation of the items to the package body. For items such as types and signals, the complete definition is needed in the external view. However, for subprogram. As users of a subprogram, we need not be concerned with how it achieves its effect or calculates its result. This is an example of a general principle called information hiding: making an interface visible but hiding the details of implementation. To illustrate this idea, suppose we have a package declaration that defines a bit-vector subtype:

subtype word32 is bit_vector(31 downto 0);

We can include in the package a procedure to do addition onWord32 values that represent signed integers. The procedure declaration in the package declaration is:

procedure add ( a, b : in word32; result : out word32; overflow : out boolean );

Note that we do not include the keyword is or any of the local declarations or statements needed to perform the addition. These are deferred to the package body. All we include is the description of the formal parameters of the procedure. Similarly, we might include a function to perform an arithmetic comparison of two word32 values:

function "<" ( a, b : in word 32 ) return boolean;

Again, we omit the local declarations and statements, simply specifying the formal parameters and the result type of the function.

Constants in Package Declarations

Just as we can apply the principle of information hiding to subprograms declared in a package, we can also apply it to constants declared in a package. The external view of a constant is just its name and type. We need to know these in order to use it, but we do not actually need to know its value. This may seem strange at first, but if we recall that the idea of introducing constant declarations in the first place was to avoid scattering literal values throughout a model, it makes more sense. We defer specifying the value of a constant declared in a package by omitting the initialization expression, for example:

constant max_buffer_size : positive;

This defines the constant to be a positive integer value. However, since we cannot see the actual value, we are not tempted to write the value as an integer literal in a model that uses the package. The specification of the actual value is deferred to the package body; where it is not visible to a model that uses the package. Given the above deferred constant in a package declaration, the corresponding package body must include the full constant declaration, for example:

constant max_buffer_size : positive := 4096;

Note that we do not have to defer the value in a constant declaration—it is optional...

Table of Contents

Preface     xiii
Fundamental Concepts     1
Modeling Digital Systems     1
Domains and Levels of Modeling     3
Modeling Example     3
Modeling Languages     7
VHDL Modeling Concepts     7
Elements of Behavior     8
Elements of Structure     10
Mixed Structural and Behavioral Models     12
Test Benches     13
Analysis, Elaboration and Execution     14
Learning a New Language: Lexical Elements and Syntax     16
Lexical Elements     17
Comments     17
Identifiers     19
Reserved Words     20
Special Symbols     22
Numbers     22
Characters     23
Strings     23
Bit Strings     24
Syntax Descriptions     26
Exercises     29
Scalar Data Types and Operations     31
Constants and Variables     31
Constant and Variable Declarations     31
Variable Assignment     33
Scalar Types     34
Type Declarations     34
Integer Types     35
Floating-Point Types     38
Physical Types     39
Time     42
Enumeration Types     43
Characters     44
Booleans     46
Bits     47
Standard Logic     48
Condition Conversion     49
Type Classification     50
Subtypes     51
Type Qualification     53
Type Conversion     53
Attributes of Scalar Types     54
Expressions and Predefined Operations     57
Exercises     61
Sequential Statements     65
If Statements     65
Case Statements     68
Null Statements     74
Loop Statements     75
Exit Statements     76
Next Statements     79
While Loops     80
For Loops     82
Summary of Loop Statements     85
Assertion and Report Statements     85
Exercises     92
Composite Data Types and Operations     95
Arrays     95
Multidimensional Arrays     98
Array Aggregates     99
Array Attributes      103
Unconstrained Array Types     105
Predefined Array Types     106
Strings     106
Boolean Vectors, Integer Vectors, Real Vectors, and Time Vectors     106
Bit Vectors     107
Standard-Logic Arrays     107
String and Bit-String Literals     108
Unconstrained Array Element Types     109
Unconstrained Array Ports     111
Array Operations and Referencing     114
Logical Operators     114
Shift Operators     116
Relational Operators     117
Maximum and Minimum Operations     118
The Concatenation Operator     119
To_String Operations     119
Array Slices     120
Array Type Conversions     121
Arrays in Case Statements     124
Matching Case Statements     125
Records     127
Record Aggregates     130
Unconstrained Record Element Types     130
Exercises     133
Basic Modeling Constructs     135
Entity Declarations and Architecture Bodies     135
Concurrent Statements     139
Signal Declarations     139
Behavioral Descriptions      141
Signal Assignment     141
Conditional Signal Assignments     144
Selected Signal Assignments     145
Signal Attributes     147
Wait Statements     149
Delta Delays     153
Transport and Inertial Delay Mechanisms     156
Process Statements     162
Concurrent Signal Assignment Statements     164
Concurrent Simple Signal Assignments     164
Concurrent Conditional Signal Assignment     165
Concurrent Selected Signal Assignments     169
Concurrent Assertion Statements     171
Entities and Passive Processes     172
Structural Descriptions     174
Design Processing     184
Analysis     184
Design Libraries and Contexts     186
Elaboration     188
Execution     191
Exercises     192
Subprograms     201
Procedures     201
Return Statement in a Procedure     206
Procedure Parameters     207
Signal Parameters     211
Default Values     214
Unconstrained Array Parameters     215
Summary of Procedure Parameters     218
Concurrent Procedure Call Statements     219
Functions     221
Functional Modeling     224
Pure and Impure Functions     224
The Function now     226
Overloading     227
Overloading Operator Symbols     228
Visibility of Declarations     230
Exercises     234
Packages and Use Clauses     239
Package Declarations     239
Subprograms in Package Declarations     244
Constants in Package Declarations     244
Package Bodies     246
Local Packages     249
Use Clauses     251
Visibility of Used Declarations     255
Exercises     258
Resolved Signals     261
Basic Resolved Signals     261
Composite Resolved Subtypes     266
Summary of Resolved Subtypes     271
IEEE std_logic_1164 Resolved Subtypes     272
Resolved Signals, Ports, and Parameters     274
Resolved Ports     276
Driving Value Attribute     279
Resolved Signal Parameters     280
Exercises     281
Predefined and Standard Packages     287
The Predefined Packages standard and env     287
IEEE Standard Packages     290
Standard VHDL Mathematical Packages     290
Real Number Mathematical Package     290
Complex Number Mathematical Package     293
The std_logic_1164 Multivalue Logic System     295
Standard Integer Numeric Packages     298
Package Summary     307
Operator Overloading Summary     307
Conversion Function Summary     309
Strength Reduction Function Summary     311
Exercises     312
Aliases     315
Aliases for Data Objects     315
Aliases for Non-Data Items     320
Exercises     323
Generic Constants     325
Generic Constants     325
Exercises     332
Components and Configurations     335
Components     335
Component Declarations     335
Component Instantiation     337
Packaging Components     338
Configuring Component Instances     340
Basic Configuration Declarations     340
Configuring Multiple Levels of Hierarchy     343
Direct Instantiation of Configured Entities     346
Generic and Port Maps in Configurations     347
Deferred Component Binding     353
Exercises     355
Generate Statements     359
Generating Iterative Structures     359
Conditionally Generating Structures     365
Exercises     372
Design for Synthesis     375
Synthesizable Subsets     375
Use of Data Types     376
Scalar Types     377
Composite and Other Types     378
Interpretation of Standard Logic Values     379
Modeling Combinational Logic     380
Modeling Sequential Logic     383
Modeling Edge-Triggered Logic     384
Level-Sensitive Logic and Inferring Storage     392
Modeling State Machines     394
Modeling Memories     396
Synthesis Attributes     400
Metacomments     410
Exercises     411
Case Study: System Design Using the Gumnut Core     413
Overview of the Gumnut     413
Instruction Set Architecture     413
External Interface     418
The Gumnut Entity Declaration      420
Instruction and Data Memories     421
A Digital Alarm Clock     425
System Design     425
Synthesizing and Implementing the Alarm Clock     433
Exercises     435
Standard Packages     437
The Predefined Package standard     437
The Predefined Package env     441
The Predefined Package textio     441
Standard VHDL Mathematical Packages     443
The math_real Package     443
The math_complex Package     445
The std_logic_1164 Multivalue Logic System Package     446
Standard Integer Numeric Packages     450
The numeric_bit Package     450
The numeric_std Package     456
The numeric_bit_unsigned Package     457
The numeric_std_unsigned Package     459
VHDL Syntax     461
Design File     463
Library Unit Declarations     463
Declarations and Specifications     465
Type Definitions     468
Concurrent Statements     470
Sequential Statements     472
Interfaces and Associations     475
Expressions and Names     476
Answers to Exercises      479
References     497
Index     499

Editorial Reviews

Written for engineering students, this introduction to VHDL (a language for describing digital electronic systems for the pre- manufacturing design of hardware systems) covers such topics as scalar data types, sequential statements, composite data types, modeling constructs, subprograms, packages and use clauses, resolved signals, generic constants, and components and configurations. Annotation c. by Book News, Inc., Portland, Or.

Booknews
