Circuit and Interconnect Design for RF and High Bit-rate Applications / Edition 1

by Hugo Veenstra, John R. Long

Overview

Realizing maximum performance from high bit-rate and RF circuits requires close attention to IC technology, circuit-to-circuit interconnections (i.e., the ‘interconnect’) and circuit design. Circuit and Interconnet Design for RF and High Bit-rate Applications covers each of these topics from theory to practice, with sufficient detail to help you produce circuits that are ‘first-time right’. A thorough analysis of the interplay between on-chip circuits and interconnects is presented, including practical examples in high bit-rate and RF applications. Optimum interconnect geometries for the distribution of RF signals are described, together with simple models for standard interconnect geometries that capture characteristic impedance and propagation delay across a broad frequency range. The analyses also covers single-ended and differential geometries, so that the designer can incorporate the effects of interconnections as soon as estimated interconnect lengths are available. Application of interconnect design is illustrated using a 12.5 Gb/s crosspoint switch example taken from a volume production part.

Product Details

ISBN-13:	9781402068829
Publisher:	Springer Netherlands
Publication date:	07/07/2008
Series:	Analog Circuits and Signal Processing
Edition description:	2008
Pages:	246
Product dimensions:	6.20(w) x 9.40(h) x 0.80(d)

About the Author

John Long is Professor at the TU Delft and he is an expert in the RF / Ultrawideband field

Table of Contents

The Challenge.- Interconnect Modelling, Analysis and Design.- Device Metrics.- Cross-Connect Switch Design.- Bias Circuits Tolerating Output Voltages Above BVCEO.- Design of Synchronous High-Speed CML Circuits, a PRBS Generator.- Analysis and Design of High-Frequency LC-VCOs.
