Creo Parametric 8.0: Sheet Metal Design

by Ascent - Center for Technical Knowledge

Overview

The Creo Parametric 8.0: Sheet Metal Design learning guide enables you to use your introductory modeling skills to create sheet metal models, including walls, bends, notches, and form features. On completion of this course, you will have acquired the skills to confidently manipulate sheet metal geometry, adjust bend developed lengths, and convert solid parts.

This guide was developed against Creo Parametric 8.0.4.0.

Topics Covered

The sheet metal environment

Primary and secondary walls

Bend relief

Corner relief

Regular unbends, back bends, and cuts

Notches and punches

Bend features

Unbending complex geometry

Sheet metal forms

Documenting a sheet metal part

Converting solid parts

Sheet metal setup

Investigating a sheet metal part

Prerequisites

Access to the Creo Parametric 8.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.

Completion of the

Creo Parametric: Introduction to Solid Modeling

guide, or similar levels of prior experience using the Creo Parametric software.

Product Details

ISBN-13:	9781959504740
Publisher:	Ascent, Center for Technical Knowledge
Publication date:	10/02/2023
Series:	Creo Parametric 8.0 , #4
Pages:	498
Product dimensions:	7.50(w) x 9.25(h) x 1.00(d)
