Shape Design Sensitivity Analysis and Optimization Using the Boundary Element Method

by Zhiye Zhao

Overview

This book investigates the various aspects of shape optimization of two­ dimensional continuum structures, including shape design sensitivity analysis, structural analysis using the boundary element method (BEM), and shape optimization implementation. The book begins by reviewing the developments of shape optimization, followed by the presentation of the mathematical programming methods for solving optimization problems. The basic theory of the BEM is presented which will be employed later on as the numerical tool to provide the structural responses and the shape design sensitivities. The key issue of shape optimization, the shape design sensitivity analysis, is fully investigated. A general formulation of stress sensitivity using the continuum approach is presented. The difficulty of the modelling of the ad­ joint problem is studied, and two approaches are presented for the modelling of the adjoint problem. The first approach uses distributed loads to smooth the concentrated adjoint loads, and the second approach employs the singu­ larity subtraction method to remove the singular boundary displacements and tractions from the BEM equation. A novel finite difference based approach to shape design sensitivity is presented, which overcomes the two drawbacks of the conventional finite difference method. This approach has the advantage of being simple in concept, and eas­ ier implementation. A shape optimization program for two-dimensional continuum structures is developed, including structural analysis using the BEM, shape design sensitiv­ ity analysis, mathematical programming, and the design boundary modelling.

Product Details

ISBN-13:	9783540535188
Publisher:	Springer Berlin Heidelberg
Publication date:	04/08/1991
Series:	Lecture Notes in Engineering , #62
Edition description:	Softcover reprint of the original 1st ed. 1991
Pages:	192
Product dimensions:	6.69(w) x 9.53(h) x 0.02(d)

Table of Contents

1 Introduction.- 1.1 Introduction.- 1.2 Review of the Shape Optimization.- 1.3 References.- 2 Basic Numerical Optimization Techniques.- 2.1 Introduction.- 2.2 Basic Concepts and Terminology.- 2.3 Mathematical Programming Method.- 2.4 References.- 3 The Boundary Element Method in Elastostatics.- 3.1 Introduction.- 3.2 Review of the Boundary Element Method in Elastostatics.- 3.3 The Boundary Element Method in Elastostatics.- 3.4 Conclusion Remarks.- 3.5 References.- 4 Shape Design Sensitivity Analysis using the Boundary Element Method.- 4.1 Introduction.- 4.2 Two Basic Approaches for Design Sensitivity Analysis.- 4.3 The Implementation of the Material Derivative of Displacements.- 4.4 Stress Sensitivity Analysis by CA.- 4.5 The Modelling of the Adjoint Problem.- 4.6 Implementation of the Singularity Subtraction Method.- 4.7 A New Finite Difference Based Approach to Shape Design Sensitivity Analysis.- 4.8 Numerical Examples.- 4.9 Concluding Remarks.- 4.10 References.- 5 Shape Optimization Using the Boundary Element Method.- 5.1 Introduction.- 5.2 The Design Model and the Analysis Model.- 5.3 Shape Optimization Implementation.- 5.4 Numerical Examples.- 5.5 References.- A Fundamental Solutions of the Semi-infinite Plane.- B Derivatives of Boundary Stresses on the Normal Direction.
