State Machines using VHDL: FPGA Implementation of Serial Communication and Display Protocols

by Orhan Gazi, A.ïagri Arli

Overview

This textbook teaches students techniques for the design of advanced digital systems using Field Programmable Gate Arrays (FPGAs). The authors focus on communication between FPGAs and peripheral devices (such as EEPROM, analog-to-digital converters, sensors, digital-to-analog converters, displays etc.) and in particular state machines and timed state machines for the implementation of serial communication prools, such as UART, SPI, I²C, and display prools, such as VGA, HDMI. VHDL is used as the programming language and all topics are covered in a structured, step-by-step manner.

Product Details

ISBN-13:	9783030616977
Publisher:	Springer International Publishing
Publication date:	01/08/2021
Edition description:	1st ed. 2021
Pages:	313
Product dimensions:	6.10(w) x 9.25(h) x (d)

About the Author

Dr. Orhan GAZİ is an academician in electrical engineering working as associate professor in Çankaya University. He is graduated from Electrical and Electronics Engineering Department/Middle East Technical University, Turkiye. His research are involves channel coding, such as turbo codes and polar codes. He is interested in practical applications of communication and signal processing subjects in FPGA devices. He is the author of 10 books in electrical engineering subjects, and six of these books are international edition.

Dr. A. Çağrı Arlı is a Senior Design and Verification Engineer at Electra IC, in Ankara. He is graduated from Electronic and Communication Engineering Department/Çankaya University. His areas of interest are Communication Theory, 5G Technologies and FPGA-based design. Recently, he focused on polar codes, visible light communication and 5G physical layer implementation.

Table of Contents

State Machines and Modeling of Mathematical and Physical Problems by State Machines.- VHDL Implementation of Finite State Machines and Practical Applications.- Timed Finite State Machines in VHDL.- Serial Peripheral Interface.- Inter integrated circuit (I²C) Serial Communication in VHDL.- Video Graphic Array (VGA) and HDMI Interfacing.
