Design of Low-Noise Amplifiers for Ultra-Wideband Communications

by Roberto Díaz Ortega, Sunil Lalchand Khemchandani, Hugo García Vázquez, Francisco Javier del Pino Suárez

Overview

Cutting-edge techniques for ultra-wideband, low-noise amplifier design

This pioneering resource presents alternatives for implementing power- and area-efficient integrated low-noise amplifiers for ultra-wideband communications. Design methodologies for distributed amplifiers, feedback amplifiers, inductor structures with reduced area, and inductorless techniques are discussed. Cowritten by international experts in industry and academia, this book addresses the state of the art in integrated circuit design in the context of emerging systems.

Design of Low-Noise Amplifiers for Ultra-Wideband Communications covers:

• Ultra-wideband overview and system approach
• Distributed amplifiers
• Wideband low-noise amplifiers
• Feedback wideband low-noise amplifiers
• Inductorless techniques

Product Details

ISBN-13:	9780071824446
Publisher:	McGraw Hill LLC
Publication date:	01/13/2014
Sold by:	Barnes & Noble
Format:	eBook
Pages:	128
File size:	6 MB

About the Author

Roberto Díaz Ortega was a researcher at the Institute for Applied Microelectronics at the University of Las Palmas de Gran Canaria, Spain.

Sunil L. Khemchandani is a senior researcher at the Institute for Applied Microelectronics and Associate Professor of Electrical Engineering in the Department of Electronic and Automatic Engineering at the University of Las Palmas de Gran Canaria, Spain.

Hugo García Vázquez is a researcher at the Institute for Applied Microelectronics at the University of Las Palmas de Gran Canaria, Spain.

Francisco Javier del Pino Suárez is a senior researcher at the Institute for Applied Microelectronics and Associate Professor of Electrical Engineering in the Department of Electronic and Automatic Engineering at the University of Las Palmas de Gran Canaria, Spain.

Table of Contents

Nomenclature
1 Ultra-Wideband Overview and System Approach
1.1 Introduction
1.2 History of Ultra-Wideband Communications
1.3 ECMA-368/ISO/IEC 26907 Receiver Specifications
1.3.1 Operating Frequency Band
1.3.2 Receiver Sensitivity
1.4 Receiver System Design
1.4.1 Noise Figure
1.4.2 Channel Filter and ADC Specifications
1.4.3 ADC and Frontend Gain Specifications
1.4.4 Automatic Gain Control
1.4.5 Linearity Requirements
1.4.6 Synthesizer Requirements
1.4.7 Budget Simulations
1.5 Conclusions
2 Distributed Amplifiers
2.1 Introduction
2.2 Theoretical Approach
2.3 Area Optimization
2.3.1 Compact Design
2.3.2 Stacked Inductors
2.4 Experimental Results
2.5 Conclusions
3 Wideband Low-Noise Amplifiers
3.1 Introduction
3.2 Wideband Low-Noise Amplifier
3.2.1 Narrowband Inductively Degenerated Amplifier
3.2.2 Wideband Inductively Degenerated Amplifier
3.2.3 Wideband Low-Noise Amplifier Design
3.2.4 Experimental Results
3.3 Flatness Improvement
3.3.1 Circuit Description
3.3.2 Experimental Results
3.4 Wideband Folded Cascode Amplifier
3.4.1 Narrowband Folded Cascode Amplifier
3.4.2 Wideband Folded Cascode Amplifier Topology
3.4.3 Experimental Results
3.5 Conclusions
4 Feedback Wideband Low-Noise Amplifiers
4.1 Introduction
4.2 Circuit Analysis
4.3 Modified Miniatured 3D Inductor
4.4 Circuit Design
4.5 Experimental Results
4.6 Conclusions
5 Inductorless Techniques
5.1 Introduction
5.2 Common Gate LNA
5.2.1 Input Matching and Voltage Gain
5.2.2 Noise of a CG Stage
5.2.3 Differential Operation of CG Stage
5.3 Mixer Design
5.3.1 Quadrature Mixers
5.3.2 Mixers with Current Boosting
5.4 Inductorless Operation
5.5 Experimental Results
5.5.1 Frontend I
5.5.2 Frontend II
5.5.3 Comparison Between Frontends
5.6 Conclusions
Bibliography
Index
