The Quintessential PIC� Microcontroller / Edition 2

by Sid Katzen

Overview

A second edition of this book has given me the opportunity to respond to suggestions from both students and correspondents from around the world, fromdisparateregionsrangingfromScotlandtoHawaii. Sincethe time of the first edition written in the late 1990s, the Microchip PIC range has become the largest volume selling 8-bit MCU. The mid-range f- ily used in the original edition has continued to expand vigorously, with some of the exemplars used becoming essentially obsolete. In addition, the enhanced-range 16-bit instruction line has been enlarged from vir- ally nothing to form a significant proportion of the family. At the same time, new introductions to the original low- (or base-) end architecture continue apace. Because of the close relationship between the low-, mid-, high- and enhanced-range lines, the focus of the new edition has stayed with the mid-range line up. Virtually all diagrams have been modified, many extensively, and - merous additional new—gures have been added. Throughout the text, special attention has been paid to clarify the basic concepts. In Part I, Chapter 3 has been extensively rewritten with this in mind and to b- ter integrate with Chapters 4 and 5 in Part II, both of which bear only a super?cial relation to the original text. Chapter 7, covering interrupt handling, has also been largely rewritten to elucidate a difficult topic.

Product Details

ISBN-13:	9781852339425
Publisher:	Springer London
Publication date:	07/13/2005
Series:	Computer Communications and Networks
Edition description:	2nd ed. 2005
Pages:	567
Product dimensions:	6.10(w) x 9.25(h) x 0.05(d)

Table of Contents

The Fundamentals.- Digital Representation.- Logic Circuitry.- Stored Program Processing.- The Software.- The PIC16F84 Microcontroller.- The Instruction Set.- Subroutines and Modules.- Interrupt Handling.- Assembly Language Code Building Tools.- High-Level Language.- The Outside World.- The Real World.- One Byte at a Time.- One Bit at a Time.- Time Is of the Essence.- Take the Rough with the Smooth.- To Have and to Hold.- Enhancing the Family.- A Case Study.
