High Speed and Wide Bandwidth Delta-Sigma ADCs

by Muhammed Bolatkale, Lucien J. Breems, Kofi A. A. Makinwa

Overview

This book describes techniques for realizing wide bandwidth (125MHz) over-sampled analog-to-digital converters (ADCs) in nano meter-CMOS processes. The authors offer a clear and complete picture of system level challenges and practical design solutions in high-speed Delta-Sigma modulators. Readers will be enabled to implement ADCs as continuous-time delta-sigma (CT∆Σ) modulators, offering simple resistive inputs, which do not require the use of power-hungry input buffers, as well as offering inherent anti-aliasing, which simplifies system integration. The authors focus on the design of high speed and wide-bandwidth ΔΣMs that make a step in bandwidth range which was previously only possible with Nyquist converters. More specifically, this book describes the stability, power efficiency and linearity limits of ΔΣMs, aiming at a GHz sampling frequency.

Product Details

ISBN-13:	9783319058399
Publisher:	Springer International Publishing
Publication date:	05/28/2014
Series:	Analog Circuits and Signal Processing
Edition description:	2014
Pages:	133
Product dimensions:	6.10(w) x 9.25(h) x 0.02(d)

Table of Contents

Introduction.- Continuous-Time Delta-Sigma Modulator.- Continuous-Time Delta-Sigma Modulators at High Sampling Rates.- A 4GHz Continuous-Time ΔΣ ADC.- A 2GHz Continuous-Time ΔΣ ADC with Dynamic Error Correction.- Conclusions.- Appendices.
